KD-S790
1-40 (No.49788)
4.10 UPD178078GF-594 (IC701) : System CPU
• Pin layout
• Pin function
80 ~ 51
1 ~ 30
50
~
31
81
~
100
Pin No. Symbol I/O Function
1~8 NC - No use
9 VOL-DA I/O VOL IC communication line
10 VOL-CLK O VOL IC communication line
11 NC - No use
12 LCD-DA O LCD driver communication line
13 LCD-CLK O LCD driver communication line
14,15 NC - No use
16 LCD-CE O LCD driver communication line
17 SW2 I CD mechanism switch
18 PSW I CD mechanism switch
19 LED RED O Red led lighting control
20 LED BLUE O Blue led lighting control
21 VOL-1 I Encoder input
22 VOL-2 I Encoder input
23 KEY0 I Key input
24 KEY1 I Key input
25 KEY2 I Key input
26 LEVEL I Audio level input
27 AVDD - Power supply
28 SM I Signal level meter input
29 NC - No use
30 DOOR SW I Door open switch
31 NC - No use
32 AVSS - Ground
33 REGCPU - ---
34 VDD - Power supply
35 REGOSC - ---
36 X2 - System clock
37 X1 I System clock
38 GND0 - Ground
39 SD/ST I Station detector & Stereo indicator
40 GND2 - Ground
41 NC - No use
42 IFC I IF count input
43 VDDPLL - Power supply
44 OSC INPUT I FM, AM OSC input
45 NC - No use
46 GNDPLL - Ground
47 AM E.OUT O PLL error output for AM
