KD-S790
3-3
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 --------------------
CD MECHA
1
2 GE10043-210A
TOP CHASSIS
1
3 GE40135-001A
EARTH PLATE
1
4 GE30568-006A
HEAT SINK
1
5 GE30393-002A
BOTTOM COVER
1
6 FSMA3005-001
INSULATOR
1
7 QYSDST2604Z
SCREW
3
CHASSIS+CD MECH
8 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PA
9 QYSDST2604Z
SCREW
3
CHASSIS+REAR BK
10 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PW
11 QYSDST2612Z
SCREW
2
SIDE PANEL+IC B
12 QYSDSF2006M
SCREW
2
F.CHASSIS+CONEC
13 GE30823-001A
FRONT CHASSIS
1
14 QYSDST2004M
SCREW
2
15 GE30827-001A
OPEN LEVER(O.L)
1
16 GE30824-002A
LOCK LEVER(O.L)
1
17 GE30826-001A
RELEASE LEVER
1
18 GE30829-001A
LOCK LEVER(TOP)
1
19 GE30825-001A
LOCK LEVER(L)
1
20 GE30828-001A
LOCK LEVER(R)
1
21 GE40154-001A
GEAR
1
22 QZW0108-002
DAMPER
1
23 FSKW4012-002
T.SPRING
1
FOR L.LEVER(TOP
24 VKW5264-005
T.SPRING
1
FOR RELEASE LEV
25 GE40155-001A
T.SPRING
1
FOR L.LEVER(R)
26 QYSDSF2006M
SCREW
1
DAMPER+L.LEVER(
27 VKW5263-002
T.SPRING
1
FOR L.LEVER(L)
28 GE40157-001A
T.SPRING
1
LOCK LEVER(O.L.
29 GE40153-001A
T.SPRING
1
FOR OPEN LEVER
30 GE40156-001A
BLIND
1
31 GE10059-001A
FRONT PANEL
1
32 GE30809-001A
FINDER ASSY
1
33 GE40163-002A
REMOTE LENS
1
FOR REMOTE CON.
34 GE20143-001A
PRESET BUTTON
1
1-6 (LASER CUT)
35 GE30810-001A
POWER BUTTON
1
36 GE30915-001A
PUSH BUTTON
1
DISP,MODE
37 GE30813-001A
D FUNC BTN (U)
1
FM/AM
38 GE30916-001A
D FUNC BTN (D)
1
EQ/CD
39 GE30818-001A
NAVIGATION BTN
1
+10/-10
40 GE30819-001A
NAVIGATION BASE
1
41 GE40127-002A
COMP.SPRING
1
FOR NAVI BASE
42 GE30815-002A
VOLUME KNOB
1
43 GE30816-002A
SEL BUTTON
1
44 FSYH4036-053
SHEET
1
45 GE30817-002A
RIM LENS
1
46 GE30820-001A
EJECT BUTTON
1
47 VKW3001-330
COMP.SPRING
1
FOR EJECT BUTTO
48 GE30812-001A
DETACH BUTTON
1
