JVC KD-SC800R Service Manual

KD-SC800R
(No.49820)1-45
47 AM E.OUT O AM LPF
48 FM E,OUT O FM LPF
49 IC(VPP) - P.D.
50 RESET I RESET CIR
51 SW1 I CD MECHA SW
52 REMOCON I REMOCON INPUT
53 NO USE O OUTPUT L
54 TEL MUTING I TEL MUTING INPUT
55 POWER O POWER CONT
56 CD-ON O CD POWER CONT.
57 MUTING O MUTING CONT
58 STAGE1 I SETTING FOR DESTINATION
59 BUZZER O BUZZER OUTPUT
60 to 67 NO USE O OUTPUT L
68 CD-RW O RF gain control L=CD-RW H=CD-DA
69 LM O DISC LOADING AND EJECTING CONT
70 MOTOR SEL O MOTOR SELECT
71 BUCK O clock output for CD LSI
72 CCE O CE output for CD LSI
73 BUS0 I/O data output and input 0 for CD LSI
74 BUS1 I/O data output and input 1 for CD LSI
75 BUS2 I/O data output and input 2 for CD LSI
76 BUS3 I/O data output and input 3 for CD LSI
77 RST O CD LSI COMMUNICATION LINE
78 PS1 I ACC DETECTION INPUT
79 PS2 I MEMORY DETECTION
80 DETACH I DETACH DETECTION
81 RDS SCK I RDS clock input
82 GND1 - -
83 MONO O MONO BY FORCE
84 SEEK/STOP O SWITCHING SEEK & STOP
85 FM/AM O BAND SW
86 AF CK O AF check output
87 RDS DA I RDS data input
88 DIMMER IN I DIMMER IN
89 NO USE O OUTPUT L
90 IFC CONT O IF OUT CONTROL
91 UNLOCK O PLL UNLOCK MONITOR OUTPUT
92 to 97 NO USE O OUTPUT L
98 DIMMER OUT O DIMMER CTRL OUT
99 VDDPORT - -
100 GNDPORT - -
Pin No. Symbol I/O Function
