JVC KD-SC800R Service Manual

KD-SC800R
3-3
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 ------------ CD MECHA
2 GE10043-210A TOP CHASSIS
3 GE30568-006A HEAT SINK
4 GE30393-002A BOTTOM COVER
5 FSMA3005-001 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
9 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
10 QYSDST2612Z SCREW 2.6mm x 12mm SC800RE
10 QYSDST2612Z SCREW 2.6mm x 12mm(x2) SC800REX
11 QYSDSF2006M SCREW 2mm x 6mm(x2)
12 GE30823-001A F. CHASSIS ASSY
13 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
14 FSYH4036-046 SHEET
15 GE30827-001A OPEN LEVER
16 GE30824-002A LOCK LEVER(O.L)
17 GE30826-001A RELEASE LEVER
18 GE30829-001A LOCK LEVER(TOP)
19 GE30825-001A LOCK LEVER(L)
20 GE30828-001A LOCK LEVER(R)
21 GE40154-001A GEAR
22 QZW0108-002 OIL DAMPER
23 FSKW4012-002 T.SPRING
24 VKW5264-005 T.SPRING
25 GE40155-001A T.SPRING
26 QYSDSF2006M SCREW 2mm x 6mm
27 VKW5263-002 T.SPRING
28 GE40157-001A T.SPRING
29 GE40153-001A T.SPRING
30 GE40156-001A BLIND
31 GE10059-002A FRONT PANEL
32 GE20141-002A FINDER LID
33 GE20142-008A FINDER PLATE
34 GE40168-001A SPECIAL SCREW (x2)
35 GE40165-002A SHEET (x2)
36 GE40163-002A REMOTE LENS
37 GE20143-001A PRESET BUTTON
38 GE30810-001A POWER BUTTON
39 GE30915-001A PUSH BUTTON (L)
40 GE30813-001A D.FUNC BTN UP
41 GE30916-002A D.FUNC BTN DOWN
42 GE30818-001A NAVI BUTTON
43 GE30819-001A NAVI BASE
44 GE40127-002A COMP SPRING
45 GE30815-002A VOLUME KNOB
46 GE30816-002A SEL BUTTON
47 FSYH4036-053 SHEET
48 GE30817-002A RIM LENS
49 GE30820-001A EJECT BUTTON
50 VKW3001-330 COMP SPRING
51 GE30812-001A DETACH BUTTON
52 VKW3001-330 COMP SPRING
53 GE10060-002A REAR COVER
54 VKZ4777-001 MINI SCREW (x4)
55 GE30821-001A LCD CASE
56 GE30805-001A LCD LENS
57 GE30806-001A LENSCASE
58 GE40150-004A LIGHTING SHEET
59 GE40150-006A LIGHTING SHEET
60 GE30771-001A NAME PLATE
61 E70891-001 CLASS 1 LABEL
62 LV41843-001A LASER CAUTION
63 QLD0253-001 LCD MODULE
64 QNZ0442-001 LCD CONNECTOR
65 QAM0461-001 STEERING ROMOTE
66 GE30912-007A REAR BRACKET
67 QYSDST2606Z SCREW 2.6mm x 6mm
68 QYSDST2606Z SCREW 2.6mm x 6mm
69 QYSDSF2606Z SCREW 2.6mm x 6mm
 70 QMFZ047-150-T FUSE 15A
71 GE40124-001A REG BRACKET
72 GE40136-001A IC BRACKET
