KD-SC800R
3-13
Packing
Block No. [M][3][M][M]
Accessories
Block No. [M][5][M][M]
 Symbol No. Part No. Part Name Description Local
P1 FSPG4002-001 POLY BAG (x2)
P2 QPA00801205 POLY BAG 8cm x 12cm
P3 FSYH4036-068 SHEET
P4 QPA01003003 POLY BAG 10cm x 30cm
P5 QPC03004315P POLY BAG 30cm x 43cm
P6 GE30772-001A CARTON
P7 GE10070-001A EPS CUSHION
 Symbol No. Part No. Part Name Description Local
A1 GET0146-001A INST BOOK ENG GER FRE DUT
A2 GET0146-002A INST BOOK RUS SPA ITA POL SC800RE
A2 GET0146-003A INST BOOK DAN FIN SWE GRE SC800REX
A3 GET0146-004A INSTALL MANUAL ENG GER FRE DUT
A4 GET0146-005A INSTALL MANUAL RUS SPA ITA POL SC800RE
A4 GET0146-006A INSTALL MANUAL DAN FIN SWE GRE SC800REX
A5 BT-54013-5 WARRANTY CARD
A6 VND3050-002 IDENTITY CARD
A7 VND3046-001 SERIAL TICKET
A8 GE30911-001A COLOUR PAPER
A9 GE30925-004A F.PLATE ASSY
A10 LV40978-001A CAUTION SHEET
A11 VKZ4027-202 PLUG NUT
A12 VKH4871-001SS MOUNT BOLT
A13 VKZ4328-001 LOCK NUT
A14 WNS5000Z WASHER
A15 GE40130-001A HOOK (x2)
A16 GE40162-001A HEX SPANNER
A17 GE40168-001A SPECIAL SCREW (x4)
A18 FSJB3002-00C HARD CASE
A19 GE20137-003A MOUNTING SLEEVE
A20 GE20149-001A TRIM PLATE
A21 QAM0176-002 POWER CORD
KIT SRW-800R SCREW PARTS KIT A11 to A17
