34
ENGLISH
How to use the cutout plates
1 Unfold the supplied cutout plates.
2 Cut the plates out using a scissors.
3 Trim out the window and two knobs using a
knife on a rubber mat.
3
Replace with another plate (a
standard, cutout, or downloaded
plate) of your preference.
• When attaching a standard plate
• When attaching a cutout or downloaded
plate
Add the transparent plate (supplied)
between the cutout or downloaded plate
and the plate cover in order to attach the
plate cover in place.
Notes:
• Be sure to keep the hex screwdriver for future use.
• Four spare screws for the plate cover attachment
are provided with the unit. (See the Installation/
Connection Manual.)
• When you attach the plate cover, do not tighten the
screws too hard; otherwise, the plate cover might
be cracked.
Plate cover
Standard plate
Plate cover
Cutout or
downloaded
plate
Transparent plate
(supplied)
