1-40 (No.49834)
6.7 IC-PST3424U-X (IC803) : Reset
• Pin layout
• Block diagram
• Pin function
1
2
VOUT
VDD
4
3
VSS
NC
1 VOU
T
2
3
VDD
VSS
+
-
Vref
No. Pin Name Function
1 Vout Reset Signal Output PIN
2 VDD VDD PIN / Voltage Detect PIN
3 NC Non connect
4 VSS VSS PIN
