KD-SH9105
3-10
Switch board
Block No. [0][2][0][0]
Front board
Block No. [0][3][0][0]
BZ961 QAN0023-001Z BUZZER
CN321 QGA2501C1-06 CONNECTOR W-B (1-6)
CN322 QGA2501C1-07 CONNECTOR W-B (1-7)
CN701 QGF0503C1-06V CONNECTOR FFC/FPC (1-6)
CN703 QGF0503F3-07X CONNECTOR FFC/FPC (1-7)
CN901 QNZ0090-001 CAR CONNECTOR
CN941 QNZ0095-001 CONNECTOR
CN981 QGB2027M4-22S CONNECTOR B-B (1-22)
CN982 QGA2501F1-02 CONNECTOR W-B (1-2)
CN991 QGF1034C1-20X CONNECTOR FFC/FPC (1-20)
J1 QAM0105-002 CAR CABLE
PP1 QZW0010-001 STYLE PIN
TU1 QAU0204-002 TUNER
X101 QAX0264-002Z CRYSTAL 22.5792MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
CN804 QGF0503F3-07X CONNECTOR FFC/FPC (1-7)
CN805 QGF1013F1-20X CONNECTOR FFC/FPC (1-20)
CN811 QGZ2202L1-16 CONNECTOR (1-16)
S891 NSW0146-001X DETECT SW
S892 NSW0146-001X DETECT SW
S893 NSW0146-001X DETECT SW
S894 NSW0146-001X DETECT SW
S895 NSW0146-001X DETECT SW
S896 NSW0146-001X DETECT SW
Symbol No.
Part No. Part Name Description Local
IC801 MN102H60KCJ1 IC
IC802 IC-PST3424U-X IC
IC803 LH28F160BJHET93 IC
IC804 NJU7241F33-X IC
IC805 RPM6938-SV4 IC
Q801 UN2111-X TRANSISTOR
Q802 2SD601A/QR/-X TRANSISTOR
Q803 2SB709A/QR/-X TRANSISTOR
Q804 2SB709A/QR/-X TRANSISTOR
Q805 2SB709A/QR/-X TRANSISTOR
Q821 UN2211-X TRANSISTOR
Q822 UN2211-X TRANSISTOR
Q823 UN2211-X TRANSISTOR
Q824 UN2211-X TRANSISTOR
Q825 UN2211-X TRANSISTOR
Q826 UN2211-X TRANSISTOR
D801 1SS355-X SI DIODE
D802 1SS355-X SI DIODE
D803 1SS355-X SI DIODE
D804 1SS355-X SI DIODE
D805 1SS355-X SI DIODE
D806 UDZS6.2B-X Z DIODE
D807 UDZS6.2B-X Z DIODE
D808 UDZS6.2B-X Z DIODE
D809 UDZS6.2B-X Z DIODE
D810 UDZS6.2B-X Z DIODE
D811 UDZS6.2B-X Z DIODE
D812 UDZS6.2B-X Z DIODE
D813 UDZS6.2B-X Z DIODE
D814 UDZS6.2B-X Z DIODE
D821 MA152WK-X SI DIODE
Symbol No.
Part No. Part Name Description Local
D822 SML-310LT/MN/-X LED
D823 SML-310LT/MN/-X LED
D824 SML-310LT/MN/-X LED
D825 SML-310LT/MN/-X LED
D826 SML-310LT/MN/-X LED
D827 SML-310LT/MN/-X LED
D828 SML-310LT/MN/-X LED
D829 SML-310LT/MN/-X LED
D830 SML-310LT/MN/-X LED
D831 SML-310LT/MN/-X LED
D832 SML-310LT/MN/-X LED
D833 SML-310LT/MN/-X LED
D834 SML-310LT/MN/-X LED
D835 SML-310LT/MN/-X LED
D836 SML-310LT/MN/-X LED
D837 SML-310LT/MN/-X LED
D838 SML310BAT/JKL-X LED
D839 SML310BAT/JKL-X LED
D840 NSPW300BS/BRS/ LED WHITE
D841 NSPW300BS/BRS/ LED WHITE
D842 NSPW300BS/BRS/ LED WHITE
C801 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C802 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C803 NDC31HJ-300X C CAPACITOR 30pF 50V J
C804 NDC31HJ-300X C CAPACITOR 30pF 50V J
C805 NDC31HJ-471X C CAPACITOR 470pF 50V J
C806 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C807 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C808 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C809 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C810 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C811 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C812 NDC31HJ-471X C CAPACITOR 470pF 50V J
C813 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C814 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C815 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C816 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C817 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C818 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C819 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C820 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C821 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C822 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C823 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C824 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C825 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C826 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C827 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C828 NDC31HJ-221X C CAPACITOR 220pF 50V J
C829 NCB31HK-102X C CAPACITOR 1000pF 50V K
C830 NCB31HK-102X C CAPACITOR 1000pF 50V K
C831 NCB31HK-102X C CAPACITOR 1000pF 50V K
R451 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R452 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R453 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R454 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R455 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R456 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R457 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R458 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R459 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R460 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R461 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R462 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R463 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R464 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R471 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R472 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R473 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R474 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R475 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R476 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R477 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R478 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R479 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R480 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
