KD-SH9105
3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 LV40848-008A SPACER
2 QYSDST2004Z SCREW 2mm x 4mm(x5)
3 QUQ105-2207AE FFC WIRE
4 VYSH101-009 SPACER
5 LV10461-001A TOP CHASSIS
6 LV32559-003B FRONT CHASS ASS
7 LV40828-003A BLIND
8 LV42419-001A LENS SHEET
9 LV40846-017A SPACER(F)
10 WJT0057-001A E CARD WIRE
11 LV32451-001A SIDE HEAT SINK
12 LV32452-001B INSULATOR
13 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
14 QYSDSF2610Z TAPPING SCREW 2.6mm x 10mm
15 LV41200-003A SPECIAL SCREW (x3)
16 LV41200-003A SPECIAL SCREW
17 QYSDST2604Z SCREW 2.6mm x 4mm(x5)
18 QYSDST2604Z SCREW 2.6mm x 4mm(x2)
19 LV41200-001A SPECIAL SCREW
20 QYSPSP2003M SCREW 2mm x 3mm(x2)
21 LV41200-001A SPECIAL SCREW (x2)
22 LV10463-002A BOTTOM CHASSIS
23 LV32453-001A FPC GUIDE
24 LV20929-001A GUIDE RAIL(L)
25 LV20930-001A GUIDE RAIL(R)
26 LV42239-001A S PLATE(L) ASSY
27 LV42240-001A S PLATE(R) ASSY
28 LV42104-001A DETECT PLATE
29 QYSPSPU1725M SCREW 1.7mm x 2.5mm(x2)
30 LV32569-003A A BKT ASSY(L)
31 LV32570-001A A BKT ASSY(R)
32 LV42112-001A TENS SPG(L) (x2)
33 LV32459-001A ROD GEAR(SH)
34 QYWFL259013-0 WASHER 0.1mm x (x2)
35 LV32530-001A GUIDE BLOCK(R)
36 LV32531-001A GUIDE BLOCK(L)
37 LV32460-001A MOTOR BKT ASSY
38 QAR0182-001 MOTOR(FEED)
39 QYSPSPT2020Z MINI SCREW 2mm x 2mm(x2)
40 LV40847-002A SPACER
41 WJM0204-001A E-SI C WIRE C-F
42 LV42455-001A SHAFT
43 LV42437-001A ROTOR
44 LV42436-001A WORM GEAR
45 LV42115-003A GEAR S1
46 LV42116-002A GEAR S2
47 LV42117-001A GEAR S3
48 LV42118-002A GEAR S4
49 LV42119-001A GEAR S5
50 WDM215025 WASHER (x5)
51 WDM214540 WASHER
52 LV30981-005A CLUTCH ASSY
53 QYWFL266010-9 WASHER 0.1mm x
54 LV32558-003A FRONT BKT ASSY
55 LV42394-001A ABSORBER
56 LV40846-022A SPACER(F)
57 LV40846-018A SPACER(F)
58 LV40846-038A SPACER(F)
59 LV40846-022A SPACER(F)
60 LV20933-002A CONECTOR COVER
61 LV40846-018A SPACER(F)
62 LV42534-001A CONNECT PTN (x2)
63 QYSPSPU1730M SCREW 1.7mm x 3mm
64 LV32461-001A REINFORCE PLATE
65 QYSPSP2003M SCREW 2mm x 3mm(x2)
66 LV32462-001A OPEN LEVER
67 LV42122-001A TORSION SPRING
68 LV32463-001A DETACH LEVER
69 LV42123-001A DTCH LVR SHAFT
70 LV42124-001A TORSION SPRING
71 QAL0314-002 FPC
72 LV42420-001A FPC SHEET
73 LV40865-001A MINI SCREW
74 LV40865-001A MINI SCREW (x3)
75 LV40865-001A MINI SCREW (x3)
76 LV40865-001A MINI SCREW (x2)
77 LV40865-001A MINI SCREW (x2)
78 LV40865-001A MINI SCREW (x2)
79 LV40865-001A MINI SCREW (x2)
80 LV42181-002A SPECIAL SCREW (x4)
81 LV10779-001A FRONT PANEL
82 LV34112-008A FINDER
83 LV21461-001A AL PANEL
84 LV10780-002A REAR COVER
85 LV34108-001A EARTH SPRING R
86 QYSPSPU1730M SCREW 1.7mm x 3mm
87 LV21458-001A PRESET BUTTON
88 LV42456-001A SW PWB SHEET
89 LV34088-001A PUSH BUTTON 1
90 LV34089-001A PUSH BUTTON 2
91 LV34090-001A UP/DOWN BUTTON
92 LV34127-004A PUSH BUTTON 4
93 LV34111-001A DETACH BUTTON
94 LV34109-001A EJECT BUTTON
95 LV34094-001A REMOTE LENS
96 LV34110-001A PUSH BUTTON
97 LV42128-001A COMP.SPRING
98 LV34095-001A VOL KNOB ASSY
99 LV43183-001A COMP.SPRING
100 LV34098-001A KNOB RING
101 LV40848-008A SPACER
102 LV34099-001A KNOB LENS
103 VKZ4777-001 MINI SCREW (x6)
104 VKZ4777-001 MINI SCREW
105 LV40848-008A SPACER (x3)
106 QLD0232-001 LCD MODULE
107 LV34113-001A LCD HOLDER
108 LV34114-001A LCD CASE
109 LV34101-001A LCD LENS
110 LV43368-002A LCD FILTER
111 LV43369-002A COLOR SHEET
112 LV43439-001A LENS SHEET
113 LV43084-001A DOUBLE FACE
114 LV40848-034A SPACER(P)
115 LV40846-036A SPACER(F)
116 LV34129-001A NAME PLATE
117 LV41143-001A SHEET
118 GE40101-001A PIN CAP (x8)
119 LV41843-001A LASER CAUTION
120 LV41993-001A REG BKT
121 VMA4652-001SS EARTH PLATE
122 LV42297-001A IC BRACKET
123 QMFZ039-150-T FUSE 15A
124 QAM0412-001 PIN CORD ASSY
125 QAM0413-001 CAR CABLE
126 LV30943-202A REAR BRACKET
127 LV30946-006A REAR HEAT SINK
128 LV40790-002A PIN CORD BRKT
129 QYSDST2604Z SCREW 2.6mm x 4mm
130 LV41200-003A SPECIAL SCREW
131 QYSDST2606Z SCREW 2.6mm x 6mm
132 QYSDST2606Z SCREW 2.6mm x 6mm
133 QYSDST2604Z SCREW 2.6mm x 4mm(x2)
134 QYSDST2604Z SCREW 2.6mm x 4mm
135 FSKS3017-002 LED HOLDER
