ENGLISH |
SPECIFICATIONS
Auxiliary

Frequency Response (±3dB) 20Hz—20kHz
Input Maximum Voltage 1200mV
Input Impedance 30kΩ
Bluetooth
Version Bluetooth Ver.2.1+EDR
Frequency Range 2.402 GHz — 2.480 GHz
Output Power +4 dBm (MAX), 0 dBm (AVE) Power Class 2
Maximum Communication Range Line of sight approx. 10 m (32.8ft)
Profile HFP1.5 (Hands-Free Profile), A2DP (Advanced
Audio Distribution Profile), AVRCP1.3 (Audio/
Video Remote Control Profile), OPP (Object Push
Profile), PBAP (Phonebook Access Profile), SPP
(Serial Port Profile)
Audio
Maximum Output Power 50W×4
Full Bandwidth Power
(at less than 1% THD)
22W×4
Speaker Impedance 4Ω—8Ω
Preout Level/Load (USB) 2500mV/10kΩ
Preout Impedance ≤600Ω
General
Operating Voltage
(10.5V—16V allowable)
14.4V
Maximum Current Consumption 10A
Operating Temperature Range 0°C to +40°C
Installation Size (W×H×D) 182mm×53mm×106mm
(7-3/16"×2-1/8"×4-3/16")
Weight
0.66k
g (1.5lbs)
Subject to change without notice.
TUNER
FM Frequency Range 87.9MHz to 107.9MHz (200kHz step)
87.5MHz to 108.0MHz (50kHz step)
Channel Space Selection 50kHz/200kHz
Usable Sensitivity
(S/N=26dB)
8.2dBf (0.71μV/75Ω)
Quieting Sensitivity
(DINS/N=46dB)
17.2dBf (2.0μV/75Ω)
Frequency Response (±3dB) 30Hz to 15kHz
Signal-to-Noise Ratio (MONO) 64dB
Stereo Separation (1kHz) 40dB
AM Frequency Range 530kHz to 1700kHz (10kHz step)
531kHz to 1611kHz (9kHz step)
Channel Space Selection 9kHz/10kHz
Usable Sensitivity
(S/N=20dB)
29dBμ (28.2μV)
USB
USB Standard USB1.1, USB2.0 (Full speed)
Compatible Devices Mass storage class
File System FAT12/16/32
Maximum Supply Current DC5V
1A
D/A Converter 24 Bit
Frequency Response (±1dB) 20Hz to 20kHz
Signal-to-Noise Ratio (1kHz) 105dB
Dynamic Range 88dB
Channel Separation 90dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
WAV Decode RIFF waveform Audio Format (Linear PCM only)
FLAC Decode FLAC files

JVC KD-X31MBS Specifications

General

Bluetooth	Yes
USB Port	Yes
Radio Tuner	AM/FM
Display Type	LCD
DIN Size	Single DIN
Detachable Face	Yes
Preamp Voltage	2.5 Volts
Peak Output	50 Watts
RMS Power Bandwidth	20 Hz - 20 kHz
Sub Preamp Outputs	1
Auxiliary Input	Yes
USB Input	Yes
iPod Compatibility	Yes
Android Compatibility	Yes
HD Radio	No
Satellite Radio Ready	No
Memory Card Slot	No
MP3 Playback	Yes
WMA Playback	Yes
AAC Playback	Yes
WAV Playback	Yes
FLAC Playback	Yes
Remote Control	Optional
Steering Wheel Control	Yes
High-Pass Filter	Yes
Low-Pass Filter	Yes
Subwoofer Output	Yes
RMS Power Output	22 watts
Preamp Outputs	3
EQ	Yes
Power Output	50W x 4
