KS-FX621
(No.49825)1-19
Head section view
Cassette mechanism
(Surface)
Arrangement of adjusting & test points
Azimuth screw
(Forward)
Playback head
Tape speed adjust
Motor assembly
Azimuth screw B
(Reverse)
Azimuth screw A
(Forward)
Playback head
Azimuth screw B
(Reverse)
