KS-FX621
3-13
Packing
Block No. [M][3][M][M]
Accessories
Block No. [M][5][M][M]
Symbol No.
Part No. Part Name Description Local
P1 FSPG4002-001 POLY BAG
P2 QPA00801205 POLY BAG 8cm x 12cm
P3 QPA01003003 POLY BAG 10cm x 30cm
P4 FSYH4036-068 SHEET
P5 QPC03004315P POLY BAG 30cm x 43cm
P6 GE30649-001A CARTON
P7 GE10036-001A EPS CUSHION (x2)
Symbol No.
Part No. Part Name Description Local
A1 GET0113-001A INST BOOK ENG ARA CHA INA
A2 GET0113-002A INSTALL MANUAL ENG ARA CHA INA
A3 VKZ4027-202 PLUG NUT
A4 VKH4871-001SS MOUNT BOLT
A5 VKZ4328-001 LOCK NUT
A6 WNS5000Z WASHER
A7 GE40130-001A HOOK (x2)
A8 FSJB3001-30C HARD CASE
A9 GE20137-003A MOUNTING SLEEVE
A0 GE20135-002A TRIM PLATE
A11 QAM0013-006 16P CORD ASSY
A 2 RM-RK31 REMOCON UNIT
A 3 ------------ BATTERY
KIT KSFX480K-SCREW1 SCREW PARTS KIT A3 TO A7
