Multi-Camera Connection
Using SDI
~ Controlling from Multiple Points ~
This is a setup to remotely control the PTZ cameras.
SDI output with no video drift between cameras is recommended in this multi-
camera setup.
A microphone can be connected to the camera. (Plug-in power support.)
For system in which PC is not used, control the camera with the remote
camera controller (RM-LP100).
The cameras can be controlled and monitored at multiple locations through SDI
output distribution.
Lag may occur depending on the network environment.
Model No. Description Quantity
KY-PZ100 HD PTZ Remote Camera 3
RM-LP100 Remote Camera Controller 2
DT-V24G2 * Multi-Format LCD Monitor 2
SR-HD2700 Blu-Ray Disc & HDD Recorder 3
HUB(PoE+) 1
Blackmagic Design
Blackmagic MultiView 4
Multi Viewer 2
Microphone 3
SDI Cable 14
LAN Cable (Category 5e) 5
* Selectable
