JVC KY-PZ100 User Manual

40
Multi-Camera Connection
Using HDMI (2)
This is a simple setup to remotely control the PTZ cameras.
Ana󰼍ordableHDMIswitchercanbeusedifthedistancebetweentheswitcher
and the cameras is short.
If the distance is long, an HDMI repeater is required at every 5 m point.
Thesetupcanbesimpli󰼎edbyselectingaswitcherwithbuilt-inaudiomixer.
For system in which PC is not used, control the camera with the remote
camera controller (RM-LP100).
ByaddingaPCforDSKinput,itispossibletooverlayimagesandtextsover
the video and output the video from the Program output.
Lag may occur depending on the network environment.
Model No. Description Quantity
KY-PZ100 HD PTZ Remote Camera 3
RM-LP100 Remote Camera Controller 1
DT-V24G2 * Multi-Format LCD Monitor 2
SR-HD2700 Blu-Ray Disc & HDD Recorder 1
HUB(PoE+) 1
Blackmagic Design
ATEM Television Studio /
Roland V-1HD
Switcher 1
HDMI Cable 6
Audio Cable 1
Audio System 1
LAN Cable (Category 5e) 4
* Selectable
