English - 11 -
Connections
Connector Type Cables Device
HDMI
Connection
(back&side)
SIDE AV
Side AV
(Audio/Video)
Connection
(side)
Audio/Video
Cable
Side Audio/Video
Connection Cable
SPDIF
SPDIF
(Coaxial Out)
Connection
(side)
HEADPHONE
Headphone
Connection
(side)
USB
Connection
(side)
CI
Connection
(side)
CAM
module
See the illustrations on the
third party in the market, if not
you plug all your cables into the
back of the TV before mounting
on the wall. Insert or remove the
CI module only when the TV is
used, it may block the headphone
and Side AV inputs. In this case,
it is recommended to make the
headphone and the Side AV con-
nections before the CI module is
inserted.
You should refer to the
module instruction manual for
details of the settings. The/Each
USB input of your TV supports
devices up to 500mA. Connecting
devices that have current value
above 500mA may damage your
using a HDMI cable to your TV,
to guarantee scient immunity
against parasitic frequency radia-
tion, you have to use a high speed
with ferrites.
