3-2(No.YA608<Rev.001>)
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................................... 3-2
EXPLODED VIEW PARTS LIST ................................................................................................................................. 3-2
EXPLODED VIEW ....................................................................................................................................................... 3-3
PRINTED WIRING BOARD PARTS LIST ................................................................................................................... 3-4
MAIN P.W. BOARD ASS'Y (HU-71200010) ...................................................................................................... 3-4
MPEG P.W. BOARD ASS'Y (HU-71200005) ..................................................................................................... 3-8
IR P.W. BOARD ASS'Y (HU-72200004) .......................................................................................................... 3-10
KEY P.W. BOARD ASS'Y (HU-72200003) ...................................................................................................... 3-10
LED P.W. BOARD ASS'Y (HU-72200017) ...................................................................................................... 3-10
PACKING ................................................................................................................................................................... 3-11
PACKING PARTS LIST ............................................................................................................................................. 3-11
USING P.W. BOARD & REMOTE CONTROL UNIT
EXPLODED VIEW PARTS LIST
P.W.B ASS'Y name
P.W.B ASS'Y No.
LT-42DA9BJ LT-42DA9BU
MAIN P.W.B HU-71200010 ←
MPEG P.W.B HU-71200005 ←
IR P.W.B HU-72200004 ←
KEY P.W.B HU-72200003 ←
LED P.W.B HU-72200017 ←
REMOTE CONTROL UNIT HU-0320200009 ←
Ref.No. Part No. Part Name Description Local
LV1 HU-0130100004 DIGITAL(LVDS) CABLE
1 HU-3021120001CO REAR COVER
2 GG10561-005A-HK FRONT PANEL HU-014213270
3 HU-0141300008 LCD PANEL UNIT
5 HU-0321700001 SPEAKER 4
Ω
10W 2pcs 1 set
8 HU-3010121002CO MAIN SHIELD
10 HU-3025221001PN CONTROL KNOB
12 HU-3010311001CO SIDE SHIELD
13 HU-0120000002 AC INLET
14 HU-3011503001CO POWER BRACKET
16 LC43073-001A-C STAND BASE UNIT HU-014213290
17 LC34390-001A-C SUPPORT PLATE HU-3011901001
20 HU-M1118300615 SCREW M3x6
21 HU-M1308301217 SCREW M3x12(x14)
22 HU-3011720001CO SUPPORT BRACKET
30 HU-0130100009 E-HARNESS ASSY MAIN-IR
31 HU-0130100007 E-HARNESS ASSY MAIN-KEY
32 HU-013011260 E-HARNESS ASSY MAIN-POWER UNIT
33 HU-0130100010 E-HARNESS ASSY INVERTER-POWER UNIT
34 HU-0130100012 E-HARNESS ASSY MAIN-LED
35 HU-0130100011 E-HARNESS ASSY INVERTER-POWER UNIT
101 HU-71200010 MAIN PWB
102 HU-71200005 MPEG PWB
103 HU-72200004 IR PWB
104 HU-72200003 KEY PWB
105 HU-014031390 POWER UNIT
106 HU-72200017 LED PWB
To Next Page
