3-10(No.YA608<Rev.001>)
IR P.W. BOARD ASS'Y (HU-72200004)
KEY P.W. BOARD ASS'Y (HU-72200003)
LED P.W. BOARD ASS'Y (HU-72200017)
R904 HU-002000433 MG RESISTOR 0 Ω
R905 HU-002000433 MG RESISTOR 0 Ω
R906 HU-002000433 MG RESISTOR 0 Ω
R907 HU-002000433 MG RESISTOR 0 Ω
R908 HU-002000433 MG RESISTOR 0 Ω
R909 HU-002000433 MG RESISTOR 0 Ω
R911 HU-002000526 MG RESISTOR 3.3k Ω
L1 NQR0129-003X FERRITE BEADS
L40 NQR0129-003X FERRITE BEADS
L130 NQR0154-002X FERRITE CORE
L131 NQR0154-002X FERRITE CORE
L132 NQR0154-002X FERRITE CORE
L180 NQR0154-007X FERRITE CORE
L181 NQR0154-007X FERRITE CORE
L182 NQR0154-007X FERRITE CORE
L183 NQR0154-007X FERRITE CORE
L184 NQR0154-007X FERRITE CORE
L380 NQR0154-002X FERRITE CORE
L381 HU-002000090 COIL
L382 HU-002000090 COIL
L383 NQR0154-002X FERRITE CORE
L385 NQR0154-002X FERRITE CORE
L386 NQR0154-002X FERRITE CORE
L390 NQR0154-002X FERRITE CORE
L391 NQR0154-002X FERRITE CORE
L392 NQR0154-002X FERRITE CORE
L393 NQR0154-002X FERRITE CORE
L430 HU-002000090 COIL
L431 HU-002000090 COIL
L530 NQR0154-002X FERRITE CORE
L531 NQR0154-002X FERRITE CORE
L580 NQR0154-002X FERRITE CORE
L750 NQR0154-002X FERRITE CORE
L805 NQR0154-007X FERRITE CORE
L900 NQR0154-002X FERRITE CORE
L901 HU-011030025 FERRITE BEADS
L902 HU-011030025 FERRITE BEADS
JP40 HU-009030060 PCMCIA CONNECTOR CI SLOT
Y180 HU-005000940 CRYSTAL 16MHz
Y430 HU-005001080 CRYSTAL 27MHz
 Ref No. Part No. Part Name Description Local
U1 HU-006050270 REMOCON SENSOR
D1 HU-006020000 LED
C1 HU-001060288 C CAPACITOR 1uF 25V
C2 HU-001060288 C CAPACITOR 1uF 25V
C3 HU-0010900002 TA CAPACITOR 220uF 10V
R10 HU-002000390 MG RESISTOR 20
Ω
RV1 HU-002110004 VARISTOR 100pF 5.6V
RV2 HU-002110004 VARISTOR 100pF 5.6V
 Ref No. Part No. Part Name Description Local
R5 HU-002001068 MG RESISTOR 270
Ω
R6 HU-002001068 MG RESISTOR 270 Ω
R7 HU-002000453 MG RESISTOR 470 Ω
R8 HU-002000453 MG RESISTOR 470 Ω
R9 HU-002000405 MG RESISTOR 1k Ω
R11 HU-002001050 MG RESISTOR 2.7k Ω
R12 HU-002000405 MG RESISTOR 1k Ω
R13 HU-002001050 MG RESISTOR 2.7k Ω
RV3 HU-002110004 VARISTOR 100pF 5.6V
RV4 HU-002110004 VARISTOR 100pF 5.6V
S1 HU-008020007 TACT SWITCH TV/AV
S2 HU-008020007 TACT SWITCH PROGRAM +
S3 HU-008020007 TACT SWITCH MENU/OK
S4 HU-008020007 TACT SWITCH PROGRAM -
S5 HU-008020007 TACT SWITCH VOL -
S6 HU-008020007 TACT SWITCH POWER ON/OFF
 Ref No. Part No. Part Name Description Local
S7 HU-008020007 TACT SWITCH VOL +
 Ref No. Part No. Part Name Description Local
R2 HU-002000000 MG RESISTOR 0
Ω
LED1 HU-0141300007 LED
RV5 HU-002110004 VARISTOR 100pF 5.6V
 Ref No. Part No. Part Name Description Local
