(No.YA608<Rev.001>)3-9
C753 HU-001060250 C CAPACITOR 0.1uF 16V K
C754 HU-001071192 E CAPACITOR 10uF 25V
C755 HU-001071192 E CAPACITOR 10uF 25V
C756 HU-001060250 C CAPACITOR 0.1uF 16V K
C757 HU-001060250 C CAPACITOR 0.1uF 16V K
C802 HU-001060286 C CAPACITOR 10uF 10V
C803 HU-001071223 E CAPACITOR 100uF 16V
C804 HU-001071223 E CAPACITOR 100uF 16V
C806 HU-001060286 C CAPACITOR 10uF 10V
C807 HU-001060286 C CAPACITOR 10uF 10V
C809 HU-001071223 E CAPACITOR 100uF 16V
C810 HU-001060286 C CAPACITOR 10uF 10V
C811 HU-001060286 C CAPACITOR 10uF 10V
C812 HU-001071223 E CAPACITOR 100uF 16V
C813 HU-001060250 C CAPACITOR 0.1uF 16V K
C814 HU-001060250 C CAPACITOR 0.1uF 16V K
C815 HU-001060249 C CAPACITOR 100pF 50V J
C816 HU-001071223 E CAPACITOR 100uF 16V
C817 HU-001060250 C CAPACITOR 0.1uF 16V K
C819 HU-001071223 E CAPACITOR 100uF 16V
C820 HU-001060286 C CAPACITOR 10uF 10V
C821 HU-001060286 C CAPACITOR 10uF 10V
C822 HU-001071228 E CAPACITOR 470uF 16V
C823 HU-001060250 C CAPACITOR 0.1uF 16V K
C824 HU-001060250 C CAPACITOR 0.1uF 16V K
C900 HU-001060250 C CAPACITOR 0.1uF 16V K
C901 HU-001060250 C CAPACITOR 0.1uF 16V K
C902 HU-001060250 C CAPACITOR 0.1uF 16V K
C903 HU-001071194 E CAPACITOR 100uF 25V
C904 HU-001071194 E CAPACITOR 100uF 25V
C905 HU-001060250 C CAPACITOR 0.1uF 16V K
C906 HU-001071194 E CAPACITOR 100uF 25V
PR2 HU-002070006 NET RESISTOR 47
Ω x4
PR3 HU-002070006 NET RESISTOR 47
Ω x4
PR5 HU-002070006 NET RESISTOR 47
Ω x4
PR6 HU-002070006 NET RESISTOR 47
Ω x4
PR40 HU-002070003 NET RESISTOR 10k
Ω x4
PR41 HU-002070003 NET RESISTOR 10k
Ω x4
PR180 HU-002070050 NET RESISTOR 47
Ω x4
PR181 HU-002070050 NET RESISTOR 47
Ω x4
PR182 HU-002070050 NET RESISTOR 47
Ω x4
PR380 HU-002070039 NET RESISTOR 33
Ω x4
PR381 HU-002070039 NET RESISTOR 33
Ω x4
PR382 HU-002070039 NET RESISTOR 33
Ω x4
PR383 HU-002070039 NET RESISTOR 33
Ω x4
PR384 HU-002070039 NET RESISTOR 33
Ω x4
PR385 HU-002070039 NET RESISTOR 33
Ω x4
PR386 HU-002070039 NET RESISTOR 33
Ω x4
PR387 HU-002070039 NET RESISTOR 33
Ω x4
PR750 HU-002070014 NET RESISTOR 33
Ω x4
R1 HU-002000090 COIL
R3 HU-002000520 MG RESISTOR 47
Ω
R4 HU-002000520 MG RESISTOR 47 Ω
R6 HU-002000520 MG RESISTOR 47 Ω
R9 HU-002000520 MG RESISTOR 47 Ω
R10 HU-002000520 MG RESISTOR 47 Ω
R11 HU-002000520 MG RESISTOR 47 Ω
R12 HU-002000437 MG RESISTOR 10k Ω
R13 HU-002000417 MG RESISTOR 4.7k Ω
R16 HU-002000417 MG RESISTOR 4.7k Ω
R18 HU-002000090 COIL
R40 HU-002000087 MG RESISTOR 4.7k
Ω
R41 HU-002000096 MG RESISTOR 10k Ω
R42 HU-002000417 MG RESISTOR 4.7k Ω
R43 HU-002000538 MG RESISTOR 120 Ω
R45 HU-002000417 MG RESISTOR 4.7k Ω
R46 HU-002000096 MG RESISTOR 10k Ω
R47 HU-002000437 MG RESISTOR 10k Ω
R48 HU-002000437 MG RESISTOR 10k Ω
R49 HU-002000437 MG RESISTOR 10k Ω
R50 HU-002000417 MG RESISTOR 4.7k Ω
R51 HU-002000417 MG RESISTOR 4.7k Ω
R52 HU-002000437 MG RESISTOR 10k Ω
R53 HU-002000437 MG RESISTOR 10k Ω
R54 HU-002000437 MG RESISTOR 10k Ω
R55 HU-002000437 MG RESISTOR 10k Ω
R56 HU-002000437 MG RESISTOR 10k Ω
R57 HU-002000437 MG RESISTOR 10k Ω
R58 HU-002000417 MG RESISTOR 4.7k Ω
R80 HU-002000527 MG RESISTOR 100 Ω
R82 HU-002000527 MG RESISTOR 100 Ω
R84 HU-002000527 MG RESISTOR 100 Ω
R86 HU-002000527 MG RESISTOR 100 Ω
R88 HU-002000527 MG RESISTOR 100 Ω
R90 HU-002000527 MG RESISTOR 100 Ω
R92 HU-002000527 MG RESISTOR 100 Ω
R94 HU-002000527 MG RESISTOR 100 Ω
R99 HU-002000527 MG RESISTOR 100 Ω
 Ref No. Part No. Part Name Description Local
R100 HU-002000527 MG RESISTOR 100 Ω
R101 HU-002000527 MG RESISTOR 100 Ω
R102 HU-002000437 MG RESISTOR 10k Ω
R103 HU-002000417 MG RESISTOR 4.7k Ω
R104 HU-002000437 MG RESISTOR 10k Ω
R130 HU-002000436 MG RESISTOR 100k Ω
R132 HU-002000417 MG RESISTOR 4.7k Ω
R133 HU-002000436 MG RESISTOR 100k Ω
R181 HU-002000454 MG RESISTOR 47k Ω
R182 HU-002000405 MG RESISTOR 1k Ω
R184 HU-002000437 MG RESISTOR 10k Ω
R187 HU-002001050 MG RESISTOR 2.7k Ω
R188 HU-002001050 MG RESISTOR 2.7k Ω
R380 HU-002000437 MG RESISTOR 10k Ω
R381 HU-002000437 MG RESISTOR 10k Ω
R382 HU-002000437 MG RESISTOR 10k Ω
R383 HU-002000437 MG RESISTOR 10k Ω
R384 HU-002001137 MG RESISTOR 51 Ω
R386 HU-002001137 MG RESISTOR 51 Ω
R388 HU-002000417 MG RESISTOR 4.7k Ω
R389 HU-002000417 MG RESISTOR 4.7k Ω
R390 HU-002000520 MG RESISTOR 47 Ω
R391 HU-002000417 MG RESISTOR 4.7k Ω
R392 HU-002000433 MG RESISTOR 0 Ω
R394 HU-002000910 MG RESISTOR 20k Ω
R395 HU-002000910 MG RESISTOR 20k Ω
R396 HU-002000417 MG RESISTOR 4.7k Ω
R397 HU-002000417 MG RESISTOR 4.7k Ω
R398 HU-002000443 MG RESISTOR 22 Ω
R430 HU-002000437 MG RESISTOR 10k Ω
R431 HU-002000417 MG RESISTOR 4.7k Ω
R432 HU-002000417 MG RESISTOR 4.7k Ω
R433 HU-002000405 MG RESISTOR 1k Ω
R434 HU-002000552 MG RESISTOR 22k Ω
R436 HU-002000417 MG RESISTOR 4.7k Ω
R437 HU-002000417 MG RESISTOR 4.7k Ω
R438 HU-002000437 MG RESISTOR 10k Ω
R439 HU-002001138 MG RESISTOR 560 Ω
R441 HU-002000437 MG RESISTOR 10k Ω
R442 HU-002000417 MG RESISTOR 4.7k Ω
R443 HU-002000527 MG RESISTOR 100 Ω
R445 HU-002000522 MG RESISTOR 680 Ω
R446 HU-002000527 MG RESISTOR 100 Ω
R447 HU-002000522 MG RESISTOR 680 Ω
R448 HU-002000096 MG RESISTOR 10k Ω
R449 HU-002000437 MG RESISTOR 10k Ω
R480 HU-002000433 MG RESISTOR 0 Ω
R530 HU-002000433 MG RESISTOR 0 Ω
R580 HU-002000908 MG RESISTOR 330 Ω
R581 HU-002000421 MG RESISTOR 75 Ω
R582 HU-002000266 MG RESISTOR 470 Ω
R584 HU-002000266 MG RESISTOR 470 Ω
R585 HU-002000421 MG RESISTOR 75 Ω
R586 HU-002000266 MG RESISTOR 470 Ω
R587 HU-002000908 MG RESISTOR 330 Ω
R589 HU-002000266 MG RESISTOR 470 Ω
R590 HU-002000421 MG RESISTOR 75 Ω
R591 HU-002000266 MG RESISTOR 470 Ω
R592 HU-002000908 MG RESISTOR 330 Ω
R594 HU-002000266 MG RESISTOR 470 Ω
R595 HU-002000421 MG RESISTOR 75 Ω
R596 HU-002000266 MG RESISTOR 470 Ω
R597 HU-002000908 MG RESISTOR 330 Ω
R599 HU-002000266 MG RESISTOR 470 Ω
R600 HU-002000908 MG RESISTOR 330 Ω
R601 HU-002000908 MG RESISTOR 330 Ω
R630 HU-002000096 MG RESISTOR 10k Ω
R631 HU-002000090 COIL
R700 HU-002000407 MG RESISTOR 2.2K
Ω
R701 HU-002000437 MG RESISTOR 10k Ω
R702 HU-002000437 MG RESISTOR 10k Ω
R703 HU-002000437 MG RESISTOR 10k Ω
R704 HU-002000407 MG RESISTOR 2.2K Ω
R705 HU-002000437 MG RESISTOR 10k Ω
R750 HU-002000417 MG RESISTOR 4.7k Ω
R751 HU-002000453 MG RESISTOR 470 Ω
R752 HU-002000453 MG RESISTOR 470 Ω
R753 HU-002000433 MG RESISTOR 0 Ω
R800 HU-002000547 MG RESISTOR 120 Ω
R801 HU-002000509 MG RESISTOR 200 Ω
R802 HU-002000548 MG RESISTOR 1.2k Ω
R803 HU-002001152 MG RESISTOR 680 Ω
R804 HU-002000405 MG RESISTOR 1k Ω
R806 HU-002000547 MG RESISTOR 120 Ω
R807 HU-002000509 MG RESISTOR 200 Ω
R900 HU-002000433 MG RESISTOR 0 Ω
R901 HU-002000433 MG RESISTOR 0 Ω
R902 HU-002000433 MG RESISTOR 0 Ω
R903 HU-002000433 MG RESISTOR 0 Ω
 Ref No. Part No. Part Name Description Local
