(No.YA608<Rev.001>)3-7
R601 HU-002000910 MG RESISTOR 20k Ω
R602 HU-002001041 MG RESISTOR 16k Ω
R603 HU-002000437 MG RESISTOR 10k Ω
R604 HU-002000454 MG RESISTOR 47k Ω
R631 HU-002000602 MG RESISTOR 2k Ω
R632 HU-002000417 MG RESISTOR 4.7k Ω
R634 HU-002000405 MG RESISTOR 1k Ω
R635 HU-002000499 MG RESISTOR 10k Ω
R637 HU-002000417 MG RESISTOR 4.7k Ω
R638 HU-002000433 MG RESISTOR 0 Ω
R640 HU-002000417 MG RESISTOR 4.7k Ω
R641 HU-002000499 MG RESISTOR 10k Ω
R644 HU-002000433 MG RESISTOR 0 Ω
R645 HU-002000417 MG RESISTOR 4.7k Ω
R646 HU-002000417 MG RESISTOR 4.7k Ω
R647 HU-002001123 MG RESISTOR 470k Ω
R648 HU-002000433 MG RESISTOR 0 Ω
R660 HU-002000527 MG RESISTOR 100 Ω
R661 HU-002000417 MG RESISTOR 4.7k Ω
R662 HU-002000527 MG RESISTOR 100 Ω
R663 HU-002000417 MG RESISTOR 4.7k Ω
R664 HU-002000437 MG RESISTOR 10k Ω
R665 HU-002000417 MG RESISTOR 4.7k Ω
R666 HU-002000437 MG RESISTOR 10k Ω
R667 HU-002000417 MG RESISTOR 4.7k Ω
R668 HU-002000417 MG RESISTOR 4.7k Ω
R669 HU-002000437 MG RESISTOR 10k Ω
R680 HU-002000437 MG RESISTOR 10k Ω
R681 HU-002000417 MG RESISTOR 4.7k Ω
R682 HU-002000405 MG RESISTOR 1k Ω
R685 HU-002000437 MG RESISTOR 10k Ω
R691 HU-002000453 MG RESISTOR 470 Ω
R693 HU-002000470 MG RESISTOR 300 Ω
R695 HU-002000470 MG RESISTOR 300 Ω
R697 HU-002000437 MG RESISTOR 10k Ω
R710 HU-002000421 MG RESISTOR 75 Ω
R711 HU-002000421 MG RESISTOR 75 Ω
R712 HU-002000421 MG RESISTOR 75 Ω
R713 HU-002000421 MG RESISTOR 75 Ω
R721 HU-002000547 MG RESISTOR 120 Ω
R722 HU-002001173 MG RESISTOR 9.1k Ω
R723 HU-002001002 MG RESISTOR 56 Ω
R724 HU-002001064 MG RESISTOR 24k Ω
R727 HU-002000547 MG RESISTOR 120 Ω
R728 HU-002001002 MG RESISTOR 56 Ω
R729 HU-002000436 MG RESISTOR 100k Ω
R730 HU-002000547 MG RESISTOR 120 Ω
R731 HU-002000529 MG RESISTOR 5.6k Ω
R732 HU-002001002 MG RESISTOR 56 Ω
R770 HU-002000433 MG RESISTOR 0 Ω
R773 HU-002000417 MG RESISTOR 4.7k Ω
R776 HU-002000448 MG RESISTOR 33 Ω
R777 HU-002000448 MG RESISTOR 33 Ω
R779 HU-002000433 MG RESISTOR 0 Ω
R780 HU-002000421 MG RESISTOR 75 Ω
R781 HU-002000437 MG RESISTOR 10k Ω
R784 HU-002000527 MG RESISTOR 100 Ω
R785 HU-002000435 MG RESISTOR 1.5k Ω
R786 HU-002000909 MG RESISTOR 33k Ω
R787 HU-002000499 MG RESISTOR 10k Ω
R789 HU-002000435 MG RESISTOR 1.5k Ω
R791 HU-002000433 MG RESISTOR 0 Ω
R792 HU-002000433 MG RESISTOR 0 Ω
R801 HU-002000437 MG RESISTOR 10k Ω
R805 HU-002000417 MG RESISTOR 4.7k Ω
R806 HU-002000417 MG RESISTOR 4.7k Ω
R811 HU-002000527 MG RESISTOR 100 Ω
R812 HU-002000437 MG RESISTOR 10k Ω
R814 HU-002000527 MG RESISTOR 100 Ω
R815 HU-002000592 MG RESISTOR 1.6k Ω
R816 HU-002000437 MG RESISTOR 10k Ω
R817 HU-002000592 MG RESISTOR 1.6k Ω
R820 HU-002000433 MG RESISTOR 0 Ω
R821 HU-002000433 MG RESISTOR 0 Ω
R822 HU-002000433 MG RESISTOR 0 Ω
R827 HU-002000433 MG RESISTOR 0 Ω
R840 HU-002000443 MG RESISTOR 22 Ω
R841 HU-002000421 MG RESISTOR 75 Ω
R842 HU-002000443 MG RESISTOR 22 Ω
R843 HU-002000421 MG RESISTOR 75 Ω
R844 HU-002000443 MG RESISTOR 22 Ω
R845 HU-002000421 MG RESISTOR 75 Ω
R846 HU-002000405 MG RESISTOR 1k Ω
R847 HU-002001060 MG RESISTOR 220k Ω
R848 HU-002000405 MG RESISTOR 1k Ω
R849 HU-002001060 MG RESISTOR 220k Ω
RN121 HU-002070044 NET RESISTOR 33 Ω x2
RN122 HU-002070044 NET RESISTOR 33
Ω x2
RN123 HU-002070044 NET RESISTOR 33
Ω x2
 Ref No. Part No. Part Name Description Local
RN124 HU-002070044 NET RESISTOR 33 Ω x2
RN125 HU-002070044 NET RESISTOR 33
Ω x2
L2 NQR0154-002X FERRITE CORE
L3 NQR0154-002X FERRITE CORE
L4 NQR0154-002X FERRITE CORE
L5 NQR0154-002X FERRITE CORE
L6 NQR0154-002X FERRITE CORE
L7 NQR0154-002X FERRITE CORE
L8 NQR0154-002X FERRITE CORE
L9 NQR0154-002X FERRITE CORE
L10 NQR0154-002X FERRITE CORE
L11 NQR0154-002X FERRITE CORE
L12 NQR0154-002X FERRITE CORE
L13 NQR0154-002X FERRITE CORE
L14 HU-011030025 FERRITE BEADS
L15 HU-011030300 FERRITE BEADS
L16 HU-011030300 FERRITE BEADS
L180 NQR0154-002X FERRITE CORE
L200 NQR0154-002X FERRITE CORE
L201 NQR0154-002X FERRITE CORE
L230 NQL812K-1R8X PEAKING COIL 1.8uH K
L234 NQL812K-1R8X PEAKING COIL 1.8uH K
L235 NQL812K-1R8X PEAKING COIL 1.8uH K
L236 NQL812K-1R8X PEAKING COIL 1.8uH K
L260 NQL812K-1R8X PEAKING COIL 1.8uH K
L264 NQL812K-1R8X PEAKING COIL 1.8uH K
L265 NQL812K-1R8X PEAKING COIL 1.8uH K
L266 NQL812K-1R8X PEAKING COIL 1.8uH K
L331 HU-011030006 BEAD
L332 HU-011030006 BEAD
L378 HU-011000056 INDUCTOR 1.8uH
L379 HU-011000056 INDUCTOR 1.8uH
L380 HU-011000056 INDUCTOR 1.8uH
L381 HU-011000056 INDUCTOR 1.8uH
L382 NQR0154-007X FERRITE CORE
L383 NQR0154-007X FERRITE CORE
L424 NQR0154-007X FERRITE CORE
L425 HU-011000056 INDUCTOR 1.8uH
L426 HU-011000056 INDUCTOR 1.8uH
L470 NQR0154-002X FERRITE CORE
L471 NQR0154-002X FERRITE CORE
L472 NQR0154-002X FERRITE CORE
L473 NQR0154-002X FERRITE CORE
L474 NQR0154-002X FERRITE CORE
L475 HU-011030320 FERRITE BEADS
L560 NQR0154-002X FERRITE CORE
L580 HU-011000056 INDUCTOR 1.8uH
L582 HU-011002180 INDUCTOR 15uH
L583 HU-011002180 INDUCTOR 15uH
L586 HU-011002180 INDUCTOR 15uH
L587 HU-011002180 INDUCTOR 15uH
L589 HU-011000056 INDUCTOR 1.8uH
L630 HU-011030300 FERRITE BEADS
L681 NQR0297-001X FERRITE CORE
L682 NQR0297-001X FERRITE CORE
L683 NQR0297-001X FERRITE CORE
L684 NQR0297-001X FERRITE CORE
L687 NQR0154-002X FERRITE CORE
L721 HU-0110000003 INDUCTOR 100mH
L723 HU-011030025 FERRITE BEADS
L724 HU-011030025 FERRITE BEADS
L840 NQL812K-1R8X PEAKING COIL 1.8uH K
L841 NQL812K-1R8X PEAKING COIL 1.8uH K
JP230 HU-0090400001 SCART CONNECTOR EXT-1
JP260 HU-0090400001 SCART CONNECTOR EXT-2
JP292 HU-009090120 OPT CONNECTOR
DIGITAL AUDIO OUT
JP330 HU-0090100001 PIN JACK EXT-3 Y/Pb/Pr
JP331 HU-009130050 PIN JACK EXT-3 AUDIO(L/R)
JP370 HU-009100750 HDMI CONNECTOR EXT-5 HDMI
JP371 HU-009100750 HDMI CONNECTOR EXT-6 HDMI
JP420 HU-009100600 HDMI CONNECTOR EXT-7 HDMI
JP580 HU-009010076 HEADPHONE JACK HEADPHONE
JP660 HU-009130030 JACK SERVICE
JP840 HU-009010036 S-JACK EXT-4 S-VIDEO
JP841 HU-009010940 PIN JACK
EXT-4 VIDEO/AUDIO(L/R)
RV230 HU-002110004 VARISTOR 100pF 5.6V
RV231 HU-002110004 VARISTOR 100pF 5.6V
RV232 HU-002110004 VARISTOR 100pF 5.6V
RV233 HU-002110004 VARISTOR 100pF 5.6V
RV234 HU-002110004 VARISTOR 100pF 5.6V
RV235 HU-002110008 VARISTOR
RV236 HU-002110008 VARISTOR
RV237 HU-002110008 VARISTOR
RV238 HU-002110008 VARISTOR
RV239 HU-002110008 VARISTOR
RV240 HU-002110004 VARISTOR 100pF 5.6V
RV241 HU-002110004 VARISTOR 100pF 5.6V
 Ref No. Part No. Part Name Description Local
