SPECIFICATION
LT-42Z49/AT, LT-42Z49/BAT, LT-42Z49/EAT, LT-42Z49/NASK, LT-42Z49/SAT, LT-42Z49/VAT
Design & specifications are subject to change without notice.
Items Contents
Dimensions (W × H × D) [without stand] 101.4 cm × 69.5 cm × 27.9 cm [101.4 cm × 64.60cm × 10.90 cm]
Mass [without stand] 20.0 kg [19.0 kg]
Power Input AC110V - AC240 V, 50 Hz / 60 Hz (Other models)
AC220V - AC240 V, 50 Hz (LT-42Z49/EAT, LT-42Z49/NASK)
Power Consumption 160 W (Standby:1.3 W)
TV RF System B, G, I, D, K, M
Colour System PAL / SECAM / NTSC 3.58 / NTSC 4.43
Stereo System A2 (B/G, D/K), NICAM (B/G, I, D/K)
Teletext System FLOF (Fastext), WST (World Standard System)
Receiving
Frequency
VHF Low
VHF High
UHF
CATV
46.25 MHz - 140.25 MHz
147.25 MHz - 423.25 MHz
431.25 MHz - 863.25 MHz
Mid (X - Z+2, S1 - S10) / Super (S11 - S20) / Hyper (S21 - S41) bands
Intermediate
Frequency
VIF
SIF
38.9 MHz (B, G, I, D, K, M)
32.26 MHz (5.74 MHz: B), 32.15 MHz (5.85 MHz: G), 31.45 MHz (6.55 MHz: I)
31.75 MHz (6.25 MHz: D), 32.15 MHz (5.85 MHz: K)
Colour Sub
Carrier
PAL
SECAM
NTSC
4.43 MHz
4.40625 MHz / 4.25 MHz
3.58 MHz / 4.43 MHz
LCD panel 42V-inch wide aspect (16 : 9)
Screen Size Diagonal: 105.0 cm (H: 93.0 cm × V: 52.3 cm)
Display Pixels Horizontal : 1920 pixels × Vertical : 1080 pixels
Audio Power Output 10 W + 10 W
Speaker 4.0 cm × 16.0 cm, oval type × 2
Aerial terminal (VHF/UHF) 75 Ω unbalanced, coaxial
Video / Audio
Input-1/2
Component Video
750p / 1125i
625p / 525p / 625i / 525i
RCA pin jack × 3
Y : 1V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75 Ω / Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1V (p-p), Positive (Negative sync provided), 75 Ω / Pb/Pr : 0.7V(p-p), 75 Ω
Video 1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 2
Audio 500mV (rms), High impedance, RCA pin jack × 4
PC (RGB) Input Video D-sub 15 pin × 1
R/G/B : 0.7 V (p-p), 75Ω
HD / VD : 1 V (p-p) to 5 V (p-p), high impedance
< Available signal >
VGA : 640 pixels × 480 pixels (Horizontal : 31.5 kHz / Vertical : 60 Hz)
XGA : 1024 pixels × 768 pixels (Horizontal : 48.4 kHz / Vertical : 60 Hz)
Audio 3.5 mm stereo mini jack × 1
HDMI Input Video/Audio(Digital) HDMI connector × 3
(Digital-input terminal is not compatible with picture signals of computer signal)
Audio (Analog) 500mV(rms) (-4dBs), high impedance, RCA pin jack × 2 [HDMI-1]
Video / Audio Output Video 1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 1
Audio 500mV (rms), Low impedance, RCA pin jack × 2
Headphone 3.5 mm stereo mini jack × 1
Remote Control Unit RM-C2510 (AAA/R6 dry cell battery × 2)
