JVC LT-42Z49/AT User Manual

(No.YA708<Rev.001>)3-39
SW P.W. BOARD ASS'Y (SFU-7610A-CK)
REMOTE P.W. BOARD ASS'Y (SFU-7611A-CK)
LED P.W. BOARD ASS'Y (SFU-8606A-CK)
POWER P.W. BOARD ASS'Y (SFU-9609A-CK)
R1145 NRSA63J-0R0X MG RESISTOR 0 Ω 1/10W J
R1146 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1147 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1148 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1149 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1150 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1151 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1152 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1153 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1154 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1156 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1157 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1160 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1161 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1162 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1163 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1202 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1205 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1208 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1211 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1213 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1214 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1215 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R1216 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R1218 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
L1001 QQL244K-4R7Z PEAKING COIL 4.7uH K
L1002 NQR0339-001X FERRITE BEADS
L1003 QQL244K-220Z P COIL 22uH K
L1004 QQL244K-180Z PEAKING COIL 18uH K
L1005 NQR0339-001X FERRITE BEADS
L1102 QQL244K-100Z PEAKING COIL 10uH K
L1202 NQL79GM-101X COIL 100uH M
L1203 NQL79GM-101X COIL 100uH M
L1204 NQL79GM-101X COIL 100uH M
CN1001 QGB1231M1-23 CONNECTOR B-B (1-23)
CN1002 QGB1231M1-23 CONNECTOR B-B (1-23)
J1001 QNN0725-004 PIN JACK VIDEO-1/OUT PUT
J1002 QNN0725-002 PIN JACK VIDEO-1/VIDEO-2
J1003 QNZ1012-001 D CONNECTOR PC IN
J1004 QNS0051-001 3.5 JACK DVI ANALOG AUDIO
J1005 QNN0833-001 PIN JACK PC AUDIO
K1101 NQR0389-003X FERRITE BEADS
K1102 NQR0389-003X FERRITE BEADS
TU1001 QAU0506-001 TUNER
 Ref No. Part No. Part Name Description Local
D7001 RKZ5.6B2KG-X Z DIODE
R7005 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7101 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R7102 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R7103 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R7104 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R7105 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R7106 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
L7001 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
J7001 QNS0072-001 HEADPHONE JACK
K7001 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
S7101 QSW1131-001Z TACT SWITCH VOL-
S7102 QSW1131-001Z TACT SWITCH VOL+
S7103 QSW1131-001Z TACT SWITCH TV/VIDEO
S7104 QSW1131-001Z TACT SWITCH POWER
S7105 QSW1131-001Z TACT SWITCH MENU/OK
S7106 QSW1131-001Z TACT SWITCH CH+
S7107 QSW1131-001Z TACT SWITCH CH-
 Ref No. Part No. Part Name Description Local
IC7301 PIC96337 PHOTO CONDUCTOR
IC7302 GP1UE281RKC1 IR DETECT UNIT
 Ref No. Part No. Part Name Description Local
D7301 RKZ5.6B2KG-X Z DIODE
D7302 RKZ5.6B2KG-X Z DIODE
C7302 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7304 NCB11AK-106X C CAPACITOR 10uF 10V K
C7305 NCB11AK-106X C CAPACITOR 10uF 10V K
R7301 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7302 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R7303 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R7304 NRSA63J-124X MG RESISTOR 120k
Ω 1/16W J
R7305 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
CN700G QJL001-072022-E SIN CR B-B WIRE
 Ref No. Part No. Part Name Description Local
Q8901 UN2212-X DIGI TRANSISTOR
Q8902 UN2110-X DIGI TRANSISTOR
D8901 SELT5E20CS/EF/T LED POWER
C8904 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R8901 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8902 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R8912 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC9201 MIP2F30MSSCF IC
IC9203 TL431/A/-T IC
IC9501 MP2A5038-F233 IC
 IC9502 FA5500AN-W IC
IC9601 TL431/A/-T IC
Q9001 2SC1623A/5-6/-X TRANSISTOR
Q9002 2SC1623A/5-6/-X TRANSISTOR
Q9201 2SK2018-01S-W POWER MOS FET
Q9501 2SK3522-01 POWER MOS FET
Q9502 2SC1623A/5-6/-X TRANSISTOR
Q9503 2SC1623A/5-6/-X TRANSISTOR
Q9504 UN2213-X DIGI TRANSISTOR
Q9505 UN2212-X DIGI TRANSISTOR
Q9506 UN2212-X DIGI TRANSISTOR
Q9507 2SB1188/QR/-W TRANSISTOR
Q9508 UN2212-X DIGI TRANSISTOR
Q9551 2SC1623A/5-6/-X TRANSISTOR
Q9555 2SB1188/QR/-W TRANSISTOR
Q9556 UN2212-X DIGI TRANSISTOR
Q9557 UN2213-X DIGI TRANSISTOR
Q9558 UN2213-X DIGI TRANSISTOR
Q9602 UN2212-X DIGI TRANSISTOR
Q9603 UN2212-X DIGI TRANSISTOR
 D9001 TS25P05G-C2 BRIDGE DIODE
D9002 1SS355W-X DIODE
D9003 1SS355W-X DIODE
D9007 UDZW3.9B-X Z DIODE
D9203 EG01C-T2 SI DIODE
D9204 SJPX-H6-W DIODE
D9208 FCH20A10 SB DIODE
D9212 EM1A-T2 SI DIODE
D9213 EM1A-T2 SI DIODE
D9214 EM1A-T2 SI DIODE
D9215 MA8330/M/-X Z DIODE
D9216 MA8150/M/-X Z DIODE
D9217 MA8150/M/-X Z DIODE
D9218 SJPX-H6-W DIODE
D9219 UDZW20B-X Z DIODE
D9220 D1FL20U-X SI DIODE
D9501 YG972S6R SI DIODE
D9502 RF101L2S-X DIODE
D9503 1SS355W-X DIODE
D9504 1SS355W-X DIODE
D9505 RF101L2S-X DIODE
D9506 1SS355W-X DIODE
 Ref No. Part No. Part Name Description Local
