JVC LT-42Z49/AT User Manual

3-26(No.YA708<Rev.001>)
SW P.W. BOARD ASS'Y (SFU-7604A-H2)
REMOTE P.W. BOARD ASS'Y (SFU-7609A-H2)
LED P.W. BOARD ASS'Y (SFU-8603A-H2)
POWER P.W. BOARD ASS'Y (SFU-9602A-H2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
DIGITALP.W. BOARD ASS'Y (SFU0D626A-H2)
R1146 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1147 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1148 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1149 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1150 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1151 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1152 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1153 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1154 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1156 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1157 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1160 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1161 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1162 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1163 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1202 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1205 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1208 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1211 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R1213 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1214 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1215 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R1216 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R1218 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
L1001 QQL244K-4R7Z PEAKING COIL 4.7uH K
L1002 NQR0339-001X FERRITE BEADS
L1003 QQL244K-220Z P COIL 22uH K
L1004 QQL244K-180Z PEAKING COIL 18uH K
L1005 NQR0339-001X FERRITE BEADS
L1102 QQL244K-100Z PEAKING COIL 10uH K
L1202 NQL79GM-101X COIL 100uH M
L1203 NQL79GM-101X COIL 100uH M
L1204 NQL79GM-101X COIL 100uH M
CN1001 QGB1231M1-23 CONNECTOR B-B (1-23)
CN1002 QGB1231M1-23 CONNECTOR B-B (1-23)
J1001 QNN0725-004 PIN JACK VIDEO-1/OUT PUT
J1002 QNN0725-002 PIN JACK VIDEO-1/VIDEO-2
J1003 QNZ1012-001 D CONNECTOR PC IN
J1004 QNS0051-001 3.5 JACK DVI ANALOG AUDIO
J1005 QNN0833-001 PIN JACK PC AUDIO
K1101 NQR0389-003X FERRITE BEADS
K1102 NQR0389-003X FERRITE BEADS
 Ref No. Part No. Part Name Description Local
D7001 RKZ5.6B2KG-X Z DIODE
R7005 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7101 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R7102 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R7103 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R7104 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R7105 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R7106 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
L7001 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
J7001 QNS0072-001 HEADPHONE JACK
K7001 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
S7101 QSW1131-001Z TACT SWITCH VOL-
S7102 QSW1131-001Z TACT SWITCH VOL+
S7103 QSW1131-001Z TACT SWITCH TV/VIDEO
S7104 QSW1131-001Z TACT SWITCH POWER
S7105 QSW1131-001Z TACT SWITCH MENU/OK
S7106 QSW1131-001Z TACT SWITCH CH+
S7107 QSW1131-001Z TACT SWITCH CH-
 Ref No. Part No. Part Name Description Local
IC7301 PIC96337 PHOTO CONDUCTOR
IC7302 GP1UE281RKC1 IR DETECT UNIT
D7301 RKZ5.6B2KG-X Z DIODE
D7302 RKZ5.6B2KG-X Z DIODE
 Ref No. Part No. Part Name Description Local
C7302 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7304 NCB11AK-106X C CAPACITOR 10uF 10V K
C7305 NCB11AK-106X C CAPACITOR 10uF 10V K
R7301 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7302 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R7303 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R7304 NRSA63J-124X MG RESISTOR 120k
Ω 1/16W J
R7305 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
CN700G QJL001-072022-E SIN CR B-B WIRE
 Ref No. Part No. Part Name Description Local
Q8901 UN2212-X DIGI TRANSISTOR
Q8902 UN2110-X DIGI TRANSISTOR
D8901 SELT5E20CS/EF/T LED POWER
C8904 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R8901 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8902 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R8912 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC6001 R2A15112FP-X IC
IC6002 BH3547F-X IC
IC6003 MC4558CD-X IC
IC6661 NJU26123VC2-X IC
IC6771 AK4384ET-X IC
IC7001 R8J66616FPA IC
IC7002 ATF64-42Z49N IC (SERVICE)
IC7003 25VF080B42Z49A IC(MICRO C ROM) (SERVICE)
IC7004 TC7WH08FU-X IC
IC7005 S-80928CLNB-G-W IC
IC9201 MM1689AH-X IC
IC9231 MM1663DH-X IC
IC9251 SI-8015Q-X IC
IC9401 SI-8005Q-X IC
IC9501 PQ090DNA1Z-X IC
IC9601 SI-8005Q-X IC
Q6104 2SC1623A/5-6/-X TRANSISTOR
Q6105 2SC1623A/5-6/-X TRANSISTOR
Q6501 2SA812A/5-6/-X TRANSISTOR
Q6503 2SC1623A/5-6/-X TRANSISTOR
Q7003 2SA812A/5-6/-X TRANSISTOR
Q7004 2SA812A/5-6/-X TRANSISTOR
Q7005 2SA812A/5-6/-X TRANSISTOR
Q7006 2SA812A/5-6/-X TRANSISTOR
Q7007 SSM3K02F-X MOS FET
Q7008 2SC1623A/5-6/-X TRANSISTOR
Q7010 SSM3K02F-X MOS FET
Q9702 2SC1623A/5-6/-X TRANSISTOR
Q9703 2SC1623A/5-6/-X TRANSISTOR
Q9704 2SC1623A/5-6/-X TRANSISTOR
Q9705 2SC1623A/5-6/-X TRANSISTOR
D6301 RKZ5.1B2KG-X Z DIODE
D6501 HSU119-X SI DIODE
D6502 HSU119-X SI DIODE
D6503 HSU119-X SI DIODE
D6504 HSU119-X SI DIODE
D6505 HSU119-X SI DIODE
D7004 RKZ5.6B2KG-X Z DIODE
D7005 RKZ5.6B2KG-X Z DIODE
D7006 RKZ5.6B2KG-X Z DIODE
D7007 RKZ5.6B2KG-X Z DIODE
 Ref No. Part No. Part Name Description Local
