(No.YA708<Rev.001>)3-29
R7063 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7065 NRSA63D-682X MG RESISTOR 6.8k
Ω
1/16W D
R7066 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7067 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7069 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7071 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7073 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7074 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7075 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R7076 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R7077 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7078 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7084 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7085 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7086 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7087 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7088 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7092 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R7093 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7094 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R7095 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7107 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7110 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7114 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7115 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7120 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R7121 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7122 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7123 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R7126 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7128 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7129 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7130 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7131 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R7133 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7134 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7135 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7136 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7137 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7138 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7139 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7142 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7143 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7144 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7145 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7146 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7147 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7148 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7149 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7150 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7151 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7152 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7153 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7154 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7155 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7156 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7157 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7158 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7159 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7161 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7163 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7164 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R7166 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7168 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7182 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7183 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7186 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R7197 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7198 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7199 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9201 NRS016J-100X MG RESISTOR 10
Ω
1W J
R9202 NRS016J-100X MG RESISTOR 10
Ω
1W J
R9203 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9204 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9251 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9252 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R9253 NRSA63D-243X MG RESISTOR 24k
Ω
1/16W D
R9254 NRSA63D-822X MG RESISTOR 8.2k
Ω
1/16W D
R9255 NRSA63D-512X MG RESISTOR 5.1k
Ω
1/16W D
R9256 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9401 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9402 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9403 NRSA63D-564X MG RESISTOR 560k
Ω
1/16W D
R9404 NRSA63D-154X MG RESISTOR 150k
Ω
1/16W D
R9405 NRSA63D-512X MG RESISTOR 5.1k
Ω
1/16W D
R9406 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9407 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9408 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9409 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R9410 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9501 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9502 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9601 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9602 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9603 NRSA63D-683X MG RESISTOR 68k
Ω
1/16W D
R9604 NRSA63D-154X MG RESISTOR 150k
Ω
1/16W D
R9605 NRSA63D-512X MG RESISTOR 5.1k
Ω
1/16W D
R9606 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R9607 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9608 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9610 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9611 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9712 NRSA63D-223X MG RESISTOR 22k
Ω
1/16W D
R9713 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
R9715 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9716 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R9717 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
RA7001 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7002 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7003 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7004 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7005 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7006 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
L6101 NQLF3EM-330X COIL 33uH M
L6102 NQLF3EM-330X COIL 33uH M
L7001 NQR0339-001X FERRITE BEADS
L7002 NQR0339-001X FERRITE BEADS
L7003 NQR0339-001X FERRITE BEADS
L7004 NQR0339-001X FERRITE BEADS
L7005 NQR0339-001X FERRITE BEADS
L7006 NQR0339-001X FERRITE BEADS
L7007 NQR0339-001X FERRITE BEADS
L7008 NQR0339-001X FERRITE BEADS
L7009 NQR0339-001X FERRITE BEADS
L7010 NQR0339-001X FERRITE BEADS
L7011 NQR0339-001X FERRITE BEADS
L7012 NQR0339-001X FERRITE BEADS
L7013 NQR0339-001X FERRITE BEADS
L7014 NQR0339-001X FERRITE BEADS
L7015 NQR0339-001X FERRITE BEADS
L7016 NQR0339-001X FERRITE BEADS
L7017 NQR0339-001X FERRITE BEADS
L7018 NQR0339-001X FERRITE BEADS
L7019 NQR0339-001X FERRITE BEADS
L7020 NQR0339-001X FERRITE BEADS
L7021 NQR0339-001X FERRITE BEADS
L7022 NQR0339-001X FERRITE BEADS
L7023 NQR0339-001X FERRITE BEADS
L7024 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L9241 NQLD7EM-150X COIL 15uH M
L9251 NQLD7EM-150X COIL 15uH M
L9401 NQLD7EM-150X COIL 15uH M
L9601 NQLD7EM-150X COIL 15uH M
CN001 QGB1231L2-23W CONNECTOR B-B (1-23)
CN002 QGB1231L2-23W CONNECTOR B-B (1-23)
J8101 NNZ0215-001X HDMI CONNECTOR DIGITAL IN
J8102 NNZ0215-001X HDMI CONNECTOR DIGITAL IN
J8103 NNZ0215-001X HDMI CONNECTOR DIGITAL IN
K6101 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6102 NQR0413-002X FERRITE BEADS
K6103 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6104 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6105 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6106 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6107 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6108 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6109 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6110 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6111 NQR0339-001X FERRITE BEADS
K6112 NQR0339-001X FERRITE BEADS
K6113 NQR0339-001X FERRITE BEADS
K6114 NQR0339-001X FERRITE BEADS
K6115 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6661 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6772 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7001 NQR0499-002X FERRITE BEADS
K7003 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
K7004 NRSA63J-0R0X MG RESISTOR 0
Ω
1/10W J
K9201 NQR0339-001X FERRITE BEADS
K9202 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9203 NQR0339-001X FERRITE BEADS
K9204 NQR0339-001X FERRITE BEADS
K9205 NQR0339-001X FERRITE BEADS
K9231 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9232 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9233 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
