JVC LT-50MA877 - Introduction

INTRODUCTION
Antenna
Main features
Accessories
50" wide screen for a complete home theater experience
Super slim LCD TV with LED backlight
3840 x 2160 native resolution for UHD performance
Integrated ATSC TV tuner for HDTV broadcast reception
Beautiful color depth with a contrast ratio of 5000:1
HDMI inputs for true digital connections
®
Specifications
Resolution:
Aspect Ratio:
TV System:
Video Signal System:
Receiving Channel:
Input Power Voltage:
Power Consumption:
YCb(Pb)Cr(Pr) Input
Viewing Picture Size(diagonal)
3840 x 2160
16:9
120W
Audio Output Power(THD 7%): 2 x 10W
NTSC
Cable :1-135/ Air: 2-69(ATV&DTV)
High-Definition Multimedia Interface(HDMI) Input x 3
x 1
50"class (50"diagonal)
Composite Video Input
AC 100-240V 50/60Hz
ATSC Digital system and NTSC Analog system
x 1
1123 x 250 x 710 mm
44.21 x 9.84 x 27.95 inch
Audio Input
Headphone Output
Coaxial
USB 2.0 Input
Dimensions (approx)
with stand fitted(WxDxH)
Net weight 11.51 kg (25.38 lbs) with STAND
x 1
x 1
x 2
x 1
Infrared Remote Control...................
1
User’s M anual ...............................
1
Battery(AAA) .................................. 2
Screws........................................... 4
Base stand......................................2
Component adaptor cable.................2
“This product is manufactured, distributed, serviced and warranted exclusively by SHENZHEN
MTC CO., LTD.. “JVC” is the trademark of JVC KENWOOD Corporation, used by such company
under license.”
-4-
LAN
x 1
The Adopted Trademarks HDMI, HDMI High-Definition Multimedia Interface, and the HDMI
Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the
United States and other countries.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the
double-D symbol are trademarks of Dolby Laboratories.
