JVC LVT1007-010A[A] Service Manual

3-5
Electrical parts list
Main board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
Q811 2SD2395/EF/ TRANTRANSISTOR
Q812 KTC3200/GL/-T TRANSISTOR
Q823 KTC3199/GL/-T TRANSISTOR
Q824 KTC3200/GL/-T TRANSISTOR
Q825 KTA1268/GL/-T TRANSISTOR
Q830 KRC109M-T DIGI TRANSISTOR
Q831 KRC109M-T DIGI TRANSISTOR
Q832 KRC109M-T DIGI TRANSISTOR
Q833 KRC109M-T DIGI TRANSISTOR
Q834 KRC109M-T DIGI TRANSISTOR
Q835 KRC109M-T DIGI TRANSISTOR
Q836 KRC109M-T DIGI TRANSISTOR
Q837 KRC109M-T DIGI TRANSISTOR
Q838 KRC109M-T DIGI TRANSISTOR
Q839 KRC109M-T DIGI TRANSISTOR
D801 30DF2-FC DIODE
D802 30DF2-FC DIODE
D803 30DF2-FC DIODE
D804 30DF2-FC DIODE
D811 MTZJ22C-T2 Z.DIODE
D816 MTZJ18C-T2 Z DIODE
D825 1SS133-T2 DIODE
D831 1SS133-T2 DIODE
D832 1SS133-T2 DIODE
D841 MTZJ5.1C-T2 Z DIODE
D842 1SS133-T2 DIODE
D843 1SS133-T2 DIODE
D844 1SS133-T2 DIODE
D845 1SS133-T2 DIODE
D846 1SS133-T2 DIODE
D847 1SS133-T2 DIODE
D848 1SS133-T2 DIODE
D851 1SS133-T2 DIODE
D852 1SS133-T2 DIODE
D853 1SS133-T2 DIODE
D871 1SS133-T2 DIODE
C454 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C801 QFZ9076-104Z MM CAPACITOR 0.1uF
C802 QFZ9076-104Z MM CAPACITOR 0.1uF
C805 QFZ9076-104Z MM CAPACITOR 0.1uF
C807 QEZ0588-688 E CAPACITOR 6800uF
C808 QEZ0588-688 E CAPACITOR 6800uF
C811 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C816 QETN1EM-476Z E CAPACITOR 47uF 25V M
C823 QETN1CM-476Z E CAPACITOR 47uF 16V M
C824 QETN1EM-106Z E CAPACITOR 10uF 25V M
C833 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C834 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C835 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C836 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C837 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C838 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C839 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C840 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C841 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C842 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C843 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C844 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C845 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C846 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C847 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C848 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C850 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C851 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C852 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C853 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C881 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C883 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C884 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C885 QFVJ1HJ-473Z MF CAPACITOR 0.047uF 50V J
C886 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C887 QFVJ1HJ-473Z MF CAPACITOR 0.047uF 50V J
C888 QFVJ1HJ-473Z MF CAPACITOR 0.047uF 50V J
C889 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C890 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C891 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C892 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C893 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C894 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C895 QFVJ1HJ-473Z MF CAPACITOR 0.047uF 50V J
C896 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C897 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C898 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C899 QCBB1HK-221Y C CAPACITOR 220pF 50V K
R801 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R802 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R811 QRJ146J-120X UNF C RESISTOR 12
Ω 1/4W J
R812 QRK126J-332X UNF C RESISTOR 3.3k
Ω 1/2W J
R813 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R814 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R815 QRJ146J-120X UNF C RESISTOR 12 Ω 1/4W J
R816 QRL027J-332 OMF RESISTOR 3.3k Ω 2W J
R823 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R824 QRE141J-134Y C RESISTOR 130k Ω 1/4W J
R825 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R826 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R831 QRZ9005-330X FUSI RESISTOR 33 Ω
R832 QRZ9005-330X FUSI RESISTOR 33 Ω
R833 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R834 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R837 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R838 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R841 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R842 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R843 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R844 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R845 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R846 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R851 QRZ9005-120X FUSI RESISTOR 12 Ω
R852 QRZ9005-330X FUSI RESISTOR 33 Ω
R854 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R855 QRJ146J-392X UNF C RESISTOR 3.9k Ω 1/4W J
R856 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R857 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R858 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R859 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R860 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R861 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R862 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R863 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R864 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R865 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R866 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R867 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R868 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R869 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R870 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R871 QRZ9005-330X FUSI RESISTOR 33 Ω
R885 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R886 QRZ9005-120X FUSI RESISTOR 12
Ω
R887 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R888 QRJ146J-100X UNF C RESISTOR 10
Ω 1/4W J
R889 QRJ146J-100X UNF C RESISTOR 10
Ω 1/4W J
L843 QQLZ005-R45 COIL 0.45uH
L844 QQLZ005-R45 COIL 0.45uH
L845 QQLZ005-R45 COIL 0.45uH
L846 QQLZ005-R45 COIL 0.45uH
CN72 QGB2510K1-06 CONNECTOR B-B (1-6)
CN82 QGB2510K1-06 CONNECTOR B-B (1-6)
CN701 QGB2510J1-12 CONNECTOR B-B (1-12)
CN702 QGB2510J1-12 CONNECTOR B-B (1-12)
 Symbol No. Part No. Part Name Description Local
