JVC MX-G70 - Page 77

MX-G70
3-17
Item
Parts number Parts name Area
Remarks
A
Q
573 2SC2785/FE/-T TRANSISTOR
Q
585 KTC3199/GL/-T TRANSISTOR
Q
586 KTC3199/GL/-T TRANSISTOR
Q
999 KRA102M-T D.TRANSISTOR
R 401 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 402 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 403 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 404 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 405 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 406 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 407 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 411 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 412 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 413 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 414 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 426 QRE141J-560Y C RESISTOR 56 5% 1/4W
R 431 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 432 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 434 QRJ146J-4R7X UNF C.RESISTOR
A
4.7 5% 1/4W
R 435 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 436 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 437 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 438 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 439 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 440 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 441 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 442 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 485 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 486 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 487 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 488 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 489 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 490 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 491 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 492 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 493 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 494 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 495 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 496 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 498 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 501 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 502 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 503 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 504 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 505 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 506 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 507 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 508 QRE141J-274Y C RESISTOR 270K 5% 1/4W
R 510 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 511 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 512 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 513 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 517 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 518 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 519 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 523 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 524 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R 526 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 528 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R 529 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 530 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 531 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 532 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 534 QRE141J-184Y C RESISTOR 180K 5% 1/4W
R 536 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 537 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 541 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 557 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 558 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 560 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 562 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 563 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 564 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 571 QRE141J-271Y C RESISTOR 270 5% 1/4W
R 572 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 575 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 576 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 577 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 579 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 580 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 581 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 582 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 583 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 585 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 586 QRE141J-225Y C RESISTOR 2.2M 5% 1/4W
R 587 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 588 QRE141J-220Y C RESISTOR 22 5% 1/4W
R 994 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 995 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 997 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 998 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 999 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1001 QRZ9044-335 COMP.RESISTOR
A
3.3M 1/0W
R1002 ERX12SJR33E UNF.C RESISTOR
A
R1202 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1203 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
Electrical parts list (Main board)
Block No. 02
Item
Parts number Parts name Area
Remarks
A
