JVC MX-G850V

1-49
MX-G950V/MX-G880V
MX-G850V/MX-G750V
1 2 3 4 5 6 7 8 9
10
GND OUT1 P1
VZ IN1 IN2
VCC1
VCC2 P2
OUT2
Input Output
Mode
IN1 IN2 OUT1 OUT2
Brake
0 0 0 0
1 0 1 0
0 1 0 1
1 1 0 0
CLOCKWISE
COUNTER-CLOCKWISE
Brake
LB1641 (IC851, IC852) : DC motor driver
1. Pin layout
2. Pin function
V
+
INPUT
+
V
-
OUTPUT
A OUT
A -IN
A +IN
V
-
1
2
3
4
A
B
(TOP VIEW)
8
7
6
5
V
+
B -IN
B +IN
B OUT
1.Terminal layout
2.Block diagram
NJM4580D (IC481, IC501, IC502, IC526, IC571) : LPF, Mic and H. phone amp.
