MX-G950V/MX-G880V
MX-G850V/MX-G750V
4-12
Item
Parts number Parts name Area
A
Parts list (Cassette mechanism)
Q'ty
Description
Block No. MPMM
1 VKS1165-00K
CHASSIS B.ASS'Y
2
2 VKR4749-004
IDLE PULLEY
2
3 LV42026-001A
SHAFT
2
5 VKS2274-002
REEL GEAR
4
6 VKW5286-002
B.T. SPRING
4
7 VKS5559-001
PLAY IDLE GEAR
2
8 VKS5597-00B
BLIND
2
9 LV42013-001A
EARTH SPRING
2
10 SLC-P1SVM
HEAD MOUNT ASSY
1
11 SLC-RP1SVM
HEAD MOUNT ASSY
1
12 VKY3149-002
CASSETTE SP.
2
13 VKM3906-004
PLAY SW.LEVER
2
14 VKS1166-004
CONTROL CAM
2
15 VKW5279-002
HEAD BASE SP(R)
2
16 VKW5280-001
HEAD BASE SP(L)
2
17 VKS5603-00G
MAIN PULLEY ASY
2
18 VKS3785-001MM
FR ARM
2
19 VKW5284-002
SWING SPRING
2
20 VKS2278-003
TRIGGER ARM
2
21 VKW5301-001
FR SPRING
2
22 VKW5266-001
ELEVATOR SPRING
2
23 WDL214025
WASHER
2
24 QYSBSF2005Z
T.SCREW
2
25 VKS3786-00G
CLUTCH ASS'Y
2
26 VKF3205-00B
F.WHEEL ASSY(R)
2
27 WDL183425
SLIT WASHER
2
28 VKF3207-00B
F.WHEEL ASSY(L)
2
29 WDL173525-6
SLIT WASHER
2
30 VKZ3174-00A
DC SOLENOID 2
31 LV42764-001A
CAPSTAN BELT(B)
2
32 MSI-5U2LWA
D.C.MOTOR ASS'Y 1
33 VKR4761-001
MOTOR PULLEY
1
34 QYSPSP2604Z
SCREW
2
35 VKM3907-001
JOINT BRACKET
1
36 QYSBSF2608Z
T.SCREW
6
37 QYSBSF2608Z
T.SCREW
5
FOR P.W.B.
