MX-G950V/MX-G880V
MX-G850V/MX-G750V
4-20
Item
Parts number Parts name Ar
e
a
Remarks
A
R 575 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 576 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 577 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 579 QRE141J-184Y C RESISTOR 180K 5% 1/4W
R 580 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 581 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 582 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 583 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 585 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 586 QRE141J-225Y C RESISTOR 2.2M 5% 1/4W
R 587 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 588 QRE141J-220Y C RESISTOR 22 5% 1/4W
R 593 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 991 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 995 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 997 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 998 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1002 ERX12SJR33E UNF.C.RESISTOR
A
R1202 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1203 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
S 500 QSW0812-001 VOLTAGE SWITCH
A
SP 21 VYSA1R3-049 SPACER
SP 22 VYSA1R3-049 SPACER
SP 23 VYSA1R3-049 SPACER
Electrical parts list (Input board)
Block No. 02
