MX-G950V/MX-G880V
MX-G850V/MX-G750V
4-22
Item
Parts number Parts name Ar
e
a
Remarks
A
JS960 QSW0911-001 ROTARY SWITCH S/MODE VOL
JS962 QSW0987-001 ROTARY ENCODER MAIN VOL
J1001 QNS0183-001 HEADPHONE JACK HEAD PHONE
J1021 QNS0184-001 JACK
J1022 QNS0184-001 JACK
L 801 QQL244K-100Z INDUCTOR
L 802 QQL231K-220Y INDUCTOR
L 803 QQL244K-100Z INDUCTOR
L 805 QQL244K-100Z INDUCTOR
L 806 QQL244K-100Z INDUCTOR
L 813 QQR1277-001Z F.BEADS
L1003 QQL231K-2R2Y INDUCTOR
Q
360 KTC2026/OY/ TRANSISTOR
A
Q
361 2SC2785/FE/-T TRANSISTOR
Q
362 2SC2785/FE/-T TRANSISTOR
Q
809 2SD1991A/RS/-T TRANSISTOR
Q
810 2SD1991A/RS/-T TRANSISTOR
Q
811 2SD1991A/RS/-T TRANSISTOR
Q
812 2SD1991A/RS/-T TRANSISTOR
Q
813 2SD1991A/RS/-T TRANSISTOR
Q
816 2SD1991A/RS/-T TRANSISTOR
Q
817 2SD1991A/RS/-T TRANSISTOR
Q
843 KRA102M-T D.TRANSISTOR
Q
858 2SD1991A/RS/-T TRANSISTOR
Q
860 2SC2785/FE/-T TRANSISTOR
Q
875 KRC102M-T D.TRANSISTOR
Q
877 KRA102M-T D.TRANSISTOR
Q
878 KRC102M-T D.TRANSISTOR
Q
879 2SD1991A/RS/-T TRANSISTOR
Q
890 2SD1991A/RS/-T TRANSISTOR
Q
905 KRC104M-T D.TRANSISTOR
Q
906 KRC104M-T D.TRANSISTOR
Q
907 KRC102M-T D.TRANSISTOR
Q
908 KRA102M-T D.TRANSISTOR
Q
918 KRC102M-T D.TRANSISTOR
Q
919 KRC102M-T D.TRANSISTOR
Q
920 KRC102M-T D.TRANSISTOR
Q
940 2SA1175/FE/-T TRANSISTOR
Q
941 2SA1175/FE/-T TRANSISTOR
Q
953 2SA1175/FE/-T TRANSISTOR
Q
954 2SA1175/FE/-T TRANSISTOR
Q
961 KRA102M-T D.TRANSISTOR
Q
1021 KRA111M-T D.TRANSISTOR
Q
1022 KRA111M-T D.TRANSISTOR
Q
1023 KRA111M-T D.TRANSISTOR
Q
1061 2SC3576-JVC-T TRANSISTOR
R 151 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 233 QRK126J-470X C RESISTOR
A
47 5% 1/2W
R 234 QRK126J-470X C RESISTOR
A
47 5% 1/2W
R 302 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 306 ERX12SJR33E UNF.C.RESISTOR
A
R 309 ERX12SJR33E UNF.C.RESISTOR
A
R 311 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 360 QRZ9042-2R2X F RESISTOR
A
2.2 1/4W
R 361 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R 362 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 363 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 364 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 365 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 366 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 367 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 368 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 801 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 807 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 808 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 810 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 811 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 812 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 813 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 814 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 815 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 816 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 817 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 818 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 819 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 820 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 821 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 822 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 823 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 824 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 825 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 826 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 827 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 828 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 829 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 831 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 832 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 833 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 834 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 835 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 836 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 837 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 838 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 839 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 840 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 841 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 842 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 844 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 845 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 846 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 847 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 848 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 849 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 850 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 851 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 854 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 855 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 856 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 857 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 858 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 859 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 860 QRE141J-684Y C RESISTOR 680K 5% 1/4W
R 861 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 862 QRE141J-220Y C RESISTOR 22 5% 1/4W
R 864 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 865 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 866 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 867 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 868 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 869 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 870 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 871 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 872 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 873 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 874 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 876 QRE141J-103Y C RESISTOR 10K 5% 1/4W
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Ar
e
a
Remarks
A
