JVC MX-G880V - Electrical parts list (CD board)

MX-G950V/MX-G880V
MX-G850V/MX-G750V
4-24
Item
Parts number Parts name Ar
e
a
Remarks
A
C 251 NCS31HJ-330X C CAPACITOR
C 252 NCS31HJ-330X C CAPACITOR
C 253 NCB31EK-104X C CAPACITOR
C 254 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 291 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 601 NCB31HK-102X C CAPACITOR
C 602 NCB31HK-102X C CAPACITOR
C 603 NCB31HK-223X C CAPACITOR
C 604 NCB31HK-223X C CAPACITOR
C 605 NCS31HJ-151X C CAPACITOR
C 606 NCS31HJ-390X C.CAPA. C.M
C 608 NCS31HJ-821X C CAPACITOR
C 610 NCB31EK-273X C CAPACITOR
C 613 NCB31EK-104X C CAPACITOR
C 614 NCB31CK-273X C CAPACITOR
C 615 NCB31HK-472X C CAPACITOR
C 616 NCB31HK-103X C CAPACITOR
C 617 NCS31HJ-331X C CAPACITOR
C 620 NCS31HJ-470X C CAPACITOR
C 621 NCB30JK-105X C CAPACITOR
C 622 NCB31EK-473X C CAPACITOR
C 623 NCF31AZ-105X C CAPACITOR
C 631 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 632 NCF31AZ-105X C CAPACITOR
C 633 NCB31HK-223X C CAPACITOR
C 641 NCB31HK-223X C CAPACITOR
C 642 NCB31HK-222X C CAPACITOR
C 651 NCS31HJ-120X C CAPACITOR
C 652 NCS31HJ-120X C CAPACITOR
C 653 NCB31EK-104X C CAPACITOR
C 655 NCB31EK-104X C CAPACITOR
C 656 NCB31EK-104X C CAPACITOR
C 657 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 658 NCB31EK-104X C CAPACITOR
C 659 NCB31HK-102X C CAPACITOR
C 661 NCS31HJ-471X C CAPACITOR
C 663 NCB31HK-223X C CAPACITOR
C 664 NCB31HK-223X C CAPACITOR
C 665 NCB31AK-154X C CAPACITOR
C 667 NCB30JK-105X C CAPACITOR
C 668 NCB31EK-473X C CAPACITOR
C 669 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 672 NCB31AK-334X C CAPACITOR
C 673 ECA1AAD101XI E CAPACITOR
C 676 NCB31EK-104X C CAPACITOR
C 677 NCB31EK-104X C CAPACITOR
C 679 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 680 NCB31EK-104X C CAPACITOR
C 801 NCB31HK-682X C CAPACITOR
C 802 NCB31HK-123X C CAPACITOR
C 811 NCS31HJ-391X C CAPACITOR
C 812 NCS31HJ-391X C CAPACITOR
C 813 NCS31HJ-391X C CAPACITOR
C 814 NCS31HJ-391X C CAPACITOR
C 821 NCF31AZ-105X C CAPACITOR
C 822 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 852 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 853 NCB31HK-103X C CAPACITOR
C 854 NCB31HK-103X C CAPACITOR
C 855 NCB31EK-104X C CAPACITOR
C 859 NCF31AZ-105X C CAPACITOR
C 860 NCF31AZ-105X C CAPACITOR
CN151 QGF1016F3-15 CONNECTOR
CN601 QGF1016F3-15 CONNECTOR
CN651 QGF1016F3-19 CONNECTOR
CN801 QGA2001C1-06 6P PLUG ASSY
CN854 QGB2016K1-07 CONNECTOR
CN855 QGG2002M4-10 CONNECTOR
D 851 DZ5.6BSB-T2 ZENER DIODE
IC251 MN101C30AEE IC
IC601 AN22000A-W IC
IC651 MN662748RPMFA IC
IC801 LA6541-X IC
IC851 LB1641 IC
IC852 LB1641 IC
L 851 QQL01BK-100Z INDUCTOR
L 853 QQL01BK-100Z INDUCTOR
L 854 QQL01BK-100Z INDUCTOR
Q
291 2SA952/LK/-T TRANSISTOR
Q
631 2SB709A/QR/-X TRANSISTOR
R 252 NRSA63J-102X MG RESISTOR
R 253 NRSA63J-102X MG RESISTOR
R 254 NRSA63J-101X MG RESISTOR
R 255 NRSA63J-101X MG RESISTOR
R 256 NRSA63J-101X MG RESISTOR
R 257 NRSA63J-102X MG RESISTOR
R 258 NRSA63J-102X MG RESISTOR
R 259 NRSA63J-102X MG RESISTOR
R 261 NRSA63J-101X MG RESISTOR
R 262 NRSA63J-101X MG RESISTOR
R 263 NRSA63J-101X MG RESISTOR
R 291 NRSA63J-122X MG RESISTOR
R 292 NRSA63J-103X MG RESISTOR
R 293 NRSA63J-102X MG RESISTOR
R 294 NRSA63J-102X MG RESISTOR
R 601 NRSA63J-224X MG RESISTOR
R 602 NRSA63J-274X MG RESISTOR
R 603 NRSA63J-124X MG RESISTOR
R 604 NRSA63J-394X MG RESISTOR
R 606 NRSA63J-623X MG RESISTOR
R 607 NRSA63J-0R0X MG RESISTOR
R 608 NRSA63J-0R0X MG RESISTOR
R 609 NRSA63J-332X MG RESISTOR
R 611 NRSA63J-223X MG RESISTOR
R 613 NRSA63J-332X MG RESISTOR
R 614 NRSA63J-223X MG RESISTOR
R 618 NRSA63J-153X MG RESISTOR
R 619 NRSA63J-153X MG RESISTOR
R 620 NRSA63J-564X MG RESISTOR
R 621 NRSA63J-564X MG RESISTOR
R 622 NRSA63J-822X MG RESISTOR
R 623 NRSA63J-822X MG RESISTOR
R 624 NRSA63J-0R0X MG RESISTOR
R 625 NRSA63J-0R0X MG RESISTOR
R 631 NRSA63J-2R2X MG RESISTOR
R 632 NRSA63J-100X MG RESISTOR
R 634 NRSA63J-120X MG RESISTOR
R 635 NRSA63J-121X MG RESISTOR
R 636 NRSA63J-100X MG RESISTOR
R 641 NRSA63J-154X MG RESISTOR
R 642 NRSA63J-394X MG RESISTOR
R 646 NRSA63J-0R0X MG RESISTOR
R 647 NRSA63J-102X MG RESISTOR
R 648 NRSA63J-102X MG RESISTOR
R 649 NRSA63J-102X MG RESISTOR
R 650 NRSA63J-102X MG RESISTOR
Electrical parts list (CD board)
Block No. 04
Item
Parts number Parts name Ar
e
a
Remarks
A
