JVC MX-G880V - Electrical parts list (VCD board)

MX-G950V/MX-G880V
MX-G850V/MX-G750V
4-26
Item
Parts number Parts name Ar
e
a
Remarks
A
C 101 NCF31CZ-104X C CAPACITOR
C 102 NCF31CZ-104X C CAPACITOR
C 103 NCF31CZ-104X C CAPACITOR
C 104 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 105 NCF31CZ-104X C CAPACITOR
C 106 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 107 NCF31CZ-104X C CAPACITOR
C 109 NCF31CZ-104X C CAPACITOR
C 110 NCF31CZ-104X C CAPACITOR
C 111 NCS31HJ-471X C CAPACITOR
C 112 NCS31HJ-471X C CAPACITOR
C 113 NCS31HJ-220X C CAPACITOR
C 114 NCB31HK-102X C CAPACITOR
C 115 NCS31HJ-220X C CAPACITOR
C 116 NCF31CZ-104X C CAPACITOR
C 117 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 118 NCF31CZ-104X C CAPACITOR
C 120 NCF31CZ-104X C CAPACITOR
C 121 NCF31CZ-104X C CAPACITOR
C 122 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 123 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 124 NCF31CZ-104X C CAPACITOR
C 125 NCF31CZ-104X C CAPACITOR
C 126 NCF31CZ-104X C CAPACITOR
C 127 NCF31CZ-104X C CAPACITOR
C 128 NCF31CZ-104X C CAPACITOR
C 129 NCF31CZ-104X C CAPACITOR
C 130 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 131 NCF31CZ-104X C CAPACITOR
C 132 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 133 NCF31CZ-104X C CAPACITOR
C 134 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 135 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 136 NCF31CZ-104X C CAPACITOR
C 137 NCB31CK-103X C CAPACITOR
C 138 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 140 NCS31HJ-220X C CAPACITOR
C 141 NCS31HJ-220X C CAPACITOR
CN101 QGF1016F3-15 CONNECTOR
CN102 QGF1016F3-15 CONNECTOR
IC101 ES3880FL IC INC TECHNOLOGY
IC102 AT27C020-70JC4 IC INC TECHNOLOGY
IC103 GLT44016-35J4-X IC SAME PARTS
IC104 ES3883F IC INC TECHNOLOGY
IC105 RT9161/A-27CG-X IC INC TECHNOLOGY
IC106 TC7S08F-W IC
IC107 TC7W08FU-X IC
K 101 NQR0398-006X FERRITE BEADS
K 102 NQR0398-006X FERRITE BEADS
K 103 NRSA02J-180X MG RESISTOR
K 104 NRSA02J-102X MG RESISTOR
L 101 NQL591K-3R3X P COIL NOT YET REGISTE
L 102 NQL591K-3R3X P COIL NOT YET REGISTE
R 101 NRSA63J-472X MG RESISTOR
R 102 NRSA63J-472X MG RESISTOR
R 103 NRSA63J-472X MG RESISTOR
R 104 NRSA63J-472X MG RESISTOR
R 105 NRSA63J-472X MG RESISTOR
R 106 NRSA63J-472X MG RESISTOR
R 107 NRSA63J-472X MG RESISTOR
R 108 NRSA63J-472X MG RESISTOR
R 109 NRSA63J-472X MG RESISTOR
R 111 NRSA63J-472X MG RESISTOR
R 112 NRSA63J-472X MG RESISTOR
R 113 NRSA63J-472X MG RESISTOR
R 119 NRSA63J-0R0X MG RESISTOR
R 120 NRSA63J-750X MG RESISTOR
R 121 NRSA63J-104X MG RESISTOR
R 128 NRSA63J-330X MG RESISTOR
R 130 NRSA63J-330X MG RESISTOR
R 132 NRSA63J-271X MG RESISTOR
R 133 NRSA63J-750X MG RESISTOR
R 134 NRSA63J-750X MG RESISTOR
R 135 NRSA63J-100X MG RESISTOR
R 136 NRSA63J-100X MG RESISTOR
R 137 NRSA63J-472X MG RESISTOR
R 138 NRSA63J-472X MG RESISTOR
R 139 NRSA63J-330X MG RESISTOR
R 140 NRSA63J-472X MG RESISTOR
R 141 NRSA63J-103X MG RESISTOR
R 142 NRSA63J-221X MG RESISTOR
R 145 NRSA63J-221X MG RESISTOR
R 146 NRSA63J-221X MG RESISTOR
R 147 NRSA63J-221X MG RESISTOR
R 148 NRSA63J-102X MG RESISTOR
X 101 QAX0700-001Z CRYSTAL
Electrical parts list (VCD board)
Block No. 05
Item
Parts number Parts name Ar
e
a
Remarks
A
