JVC MX-G880V - Electrical parts list (CD switch board)

MX-G950V/MX-G880V
MX-G850V/MX-G750V
4-28
Item
Parts number Parts name Ar
e
a
Remarks
A
CN301 QGF1205F1-06 CONNECTOR A HEAD
CN302 QGF1205F1-06 CONNECTOR B HEAD
CN303 QGB2011M1-10 B TO B CONNECTO
CN305 QGF1201F3-10 CONNECTOR OUTPUT
CN306 QGF1205F1-09 CONNECTOR CONTROL
CN333 QGB2011L1-10 B TO B CONNECTO FOR FMP-007-1
C3101 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C3102 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C3103 QDGB1HK-821Y C CAPACITOR
C3104 QDGB1HK-102Y C CAPACITOR
C3105 EEKJ1AM-107ZJC AL E CAPACITOR
C3107 EEKJ1HM-105ZJC AL E CAPACITOR
C3111 EEKJ1HM-104ZJC AL E CAPACITOR
C3112 EEKJ1CM-106ZJC AL E CAPACITOR
C3113 QDXB1CM-332Y C CAPACITOR
C3114 EEKJ1EM-475ZJC AL E CAPACITOR
C3115 QFLK1HJ-153Z M CAPACITOR .015MF 5% 50V
C3116 QDYB1CM-822Y C CAPACITOR
C3119 QFLM1HJ-563Z M CAPACITOR .056MF 5% 50V
C3120 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V
C3121 QDGB1HK-102Y C CAPACITOR
C3201 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C3202 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C3203 QDGB1HK-821Y C CAPACITOR
C3204 QDGB1HK-102Y C CAPACITOR
C3205 EEKJ1AM-107ZJC AL E CAPACITOR
C3206 QFLK1HJ-333Z M CAPACITOR .033MF 5% 50V
C3207 EEKJ1HM-105ZJC AL E CAPACITOR
C3211 EEKJ1HM-104ZJC AL E CAPACITOR
C3212 EEKJ1CM-106ZJC AL E CAPACITOR
C3213 QDXB1CM-332Y C CAPACITOR
C3214 EEKJ1EM-475ZJC AL E CAPACITOR
C3215 QFLK1HJ-153Z M CAPACITOR .015MF 5% 50V
C3216 QDYB1CM-822Y C CAPACITOR
C3219 QFLM1HJ-563Z M CAPACITOR .056MF 5% 50V
C3220 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V
C3221 QDGB1HK-102Y C CAPACITOR
C3222 QFLK1HJ-333Z M CAPACITOR .033MF 5% 50V
C3301 EEKJ1AM-107ZJC AL E CAPACITOR
C3302 EEKJ1AM-107ZJC AL E CAPACITOR
C3303 EEKJ1CM-226ZJC AL E CAPACITOR
C3304 EEKJ1EM-475ZJC AL E CAPACITOR
C3305 QFLK1HJ-393Z M CAPACITOR .039MF 5% 50V
C3306 EEKJ0JM-227ZJC AL E CAPACITOR
C3308 QDXB1CM-152Y C CAPACITOR
C3313 EEKJ1AM-107ZJC AL E CAPACITOR
C3314 QCZ0202-155Z ML C CAPACITOR 1.5MF
C3315 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
C3316 QFG32AJ-103Z PP CAPACITOR .010MF 5% 100V
C3327 EEKJ1CM-476ZJC AL E CAPACITOR
C3335 QDYB1CM-103Y C CAPACITOR
C3336 QDYB1CM-103Y C CAPACITOR
C3339 EEKJ1CM-476ZJC AL E CAPACITOR
C3340 QDYB1CM-103Y C CAPACITOR
C3341 EEKJ1AM-107ZJC AL E CAPACITOR
C3342 EEKJ1EM-475ZJC AL E CAPACITOR
C3345 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C3350 QDGB1HK-102Y C CAPACITOR
C3501 QDGB1HK-821Y C CAPACITOR
C3502 QCBB1HK-271Y C CAPACITOR 270PF 10% 50V
C3555 QDGB1HK-102Y C CAPACITOR
C3601 QDGB1HK-821Y C CAPACITOR
C3602 QCBB1HK-271Y C CAPACITOR 270PF 10% 50V
D3302 1SR139-400-T2 SI DIODE
D3307 DZ5.1BSB-T2 Z DIODE NEW SUPPLIER
D3308 DZ5.1BSB-T2 Z DIODE
D3309 DZ5.1BSB-T2 Z DIODE
D3331 1SR139-400-T2 SI DIODE
FW301 EWR34D-10CS FLAT WIRE TO MOTOR CONTRO
IC301 BA3126N IC HEAD SW
IC302 AN7345K IC PRE AMP
IC303 CD4094BC IC
IC331 SG-105F3-BB,C PHOTO SENSER
IC332 SG-105F3-BB,C PHOTO SENSER
L3202 QQR0621-001Z FERRITE BEADS
L3301 QQR1118-002 BIAS COIL OSC COIL
L3303 QQL244K-100Z INDUCTOR
P3302 QNZ0104-001 POST PIN
P3331 QNZ0104-001 POST PIN
Q
3105 2SC3576-JVC-T TRANSISTOR
Q
3205 2SC3576-JVC-T TRANSISTOR
Q
3302 2SC2001/K/-T TRANSISTOR
Q
3305 2SC2001/K/-T TRANSISTOR
Q
3312 2SB562/C/-T TRANSISTOR
Q
3313 KTC3199/GL/-T TRANSISTOR
Q
3314 2SB562/C/-T TRANSISTOR
Q
3315 KTC3199/GL/-T TRANSISTOR
Q
3316 KTA1267/YG/-T TRANSISTOR
Q
3317 KRC107M-T D TRANSISTOR
Q
3323 KRC104M-T D TRANSISTOR
Q
3324 KRA102M-T D TRANSISTOR
R3103 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R3105 QRE141J-220Y C RESISTOR 22 5% 1/4W
R3106 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R3107 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R3108 QRE141J-241Y C RESISTOR 240 5% 1/4W
R3111 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R3112 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R3113 QRE141J-271Y C RESISTOR 270 5% 1/4W
R3114 QRE141J-391Y C RESISTOR 390 5% 1/4W
R3117 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R3118 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R3119 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R3120 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R3121 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R3203 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R3205 QRE141J-220Y C RESISTOR 22 5% 1/4W
R3206 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R3207 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R3208 QRE141J-241Y C RESISTOR 240 5% 1/4W
R3211 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R3212 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R3213 QRE141J-271Y C RESISTOR 270 5% 1/4W
R3214 QRE141J-391Y C RESISTOR 390 5% 1/4W
R3217 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R3218 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R3219 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R3220 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R3221 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R3301 QRE141J-221Y C RESISTOR 220 5% 1/4W
R3302 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3304 QRE141J-393Y C RESISTOR 39K 5% 1/4W
R3309 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R3311 QRJ146J-4R7X UNF C RESISTOR 4.7 5% 1/4W
R3314 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3315 QRE141J-153Y C RESISTOR 15K 5% 1/4W
Electrical parts list
(Head amplifier & mechanism control board)
Block No.08
Item
Parts number Parts name Ar
e
a
Remarks
A
