JVC MX-G880V - Page 162

MX-G950V/MX-G880V
MX-G850V/MX-G750V
5-20
Item
Parts number Parts name Ar
e
a
Remarks
A
R 880 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 881 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 882 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 883 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 884 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 886 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 887 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 888 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 889 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 890 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 891 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 893 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 894 QRE141J-334Y C RESISTOR US,UN330K 5% 1/4W
R 894 QRE141J-183Y C RESISTOR UX18K 5% 1/4W
R 895 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 897 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 898 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 902 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 905 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 906 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 907 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 911 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 912 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 916 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 917 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 918 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 919 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 920 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 921 QRE141J-334Y C RESISTOR 330K 5% 1/4W
R 930 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 931 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 932 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 933 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 935 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 936 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 937 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 938 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 939 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 940 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 941 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 942 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 943 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 944 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 945 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 946 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 947 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 948 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 949 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 950 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 952 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 953 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 954 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 955 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 961 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 962 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 963 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 964 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 965 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 969 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 970 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 992 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 993 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 994 QRE141J-183Y C RESISTOR UX18K 5% 1/4W
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Ar
e
a
Remarks
A
R 995 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 996 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
RA801 QRB169J-104 NET RESISTOR 100K 5% 1/6W
RA802 QRB169J-104 NET RESISTOR 100K 5% 1/6W
RY 1 QSK0109-001 RELAY
R1021 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1022 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1031 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1032 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1033 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R1034 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1035 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R1036 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R1037 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1038 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1039 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1040 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R1041 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1042 QRE141J-221Y C RESISTOR 220 5% 1/4W
R1043 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1044 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R1045 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1061 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1062 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R1063 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1064 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R1065 QRE141J-101Y C RESISTOR 100 5% 1/4W
R1066 QRE141J-475Y C RESISTOR 4.7M 5% 1/4W
R1067 QRE141J-560Y C RESISTOR 56 5% 1/4W
R1068 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R1069 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1070 QRE141J-561Y C RESISTOR 560 5% 1/4W
R1071 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
S 915 QSW0825-001Z TACT SWITCH DISC 1
S 916 QSW0825-001Z TACT SWITCH
S 917 QSW0825-001Z TACT SWITCH
S 931 QSW0825-001Z TACT SWITCH DUBBING
S 932 QSW0825-001Z TACT SWITCH
S 933 QSW0825-001Z TACT SWITCH
S 935 QSW0825-001Z TACT SWITCH
S 936 QSW0825-001Z TACT SWITCH
S 937 QSW0825-001Z TACT SWITCH
S 938 QSW0825-001Z TACT SWITCH
S 939 QSW0825-001Z TACT SWITCH
S 942 QSW0825-001Z TACT SWITCH
S 943 QSW0825-001Z TACT SWITCH
S 944 QSW0825-001Z TACT SWITCH
S 945 QSW0825-001Z TACT SWITCH
S 946 QSW0825-001Z TACT SWITCH
S 947 QSW0825-001Z TACT SWITCH
S 948 QSW0825-001Z TACT SWITCH
S 949 QSW0825-001Z TACT SWITCH
S 950 QSW0825-001Z TACT SWITCH
S 951 QSW0825-001Z TACT SWITCH
S 952 QSW0825-001Z TACT SWITCH
S 963 QSW0825-001Z TACT SWITCH
S 995 QSW0825-001Z TACT SWITCH
S 996 QSW0825-001Z TACT SWITCH
S 997 QSW0825-001Z TACT SWITCH
S 998 QSW0825-001Z TACT SWITCH
S 999 QSW0825-001Z TACT SWITCH
SP801 VYH7653-001 IC HOLDER
VR901 QVQ0299-B54 V.RESISTOR
X 801 QAX0711-002Z CRYSTAL
R 994 QRE141J-753Y C RESISTOR US,UN75K 5% 1/4W
