JVC MX-G880V

3-19
MX-G950V/MX-G880V
MX-G850V/MX-G750V
Item
Parts number Parts name Ar
e
a
Remarks
A
D 592 1SS119-041-T2 SI DIODE
EP250 E409182-001SM GRAND TERMINAL
FT111 QNG0020-001Z FUSE CLIP
FT112 QNG0020-001Z FUSE CLIP
FT131 QNG0020-001Z FUSE CLIP
FT132 QNG0020-001Z FUSE CLIP
FT511 QNG0020-001Z FUSE CLIP
FT512 QNG0020-001Z FUSE CLIP
FT521 QNG0020-001Z FUSE CLIP
FT522 QNG0020-001Z FUSE CLIP
FW401 QUM155-09Z4Z4 PARA RIBON WIRE
FW710 QUM153-09DGZ4 FLAT WIRE
FW714 QUM156-18DGZ4 PARA RIBON WIRE
IC436 TDA7439 IC
IC466 BA3837 IC(VOCALFADER)
IC481 NJM4580D IC
IC501 NJM4580D IC
IC502 NJM4580D IC
IC526 NJM4580D IC
IC571 NJM4580D IC
J 411 QNN0420-001 PIN JACK
J 426 GP1FA550TZ OPT TRANSMITTER
J 999 QNN0420-001 PIN JACK
JA566 QNN0017-002 PIN JACK
L 001 QQR1277-001Z F.BEADS
L 546 QQR1277-001Z F.BEADS
L 566 QQR1277-001Z F.BEADS
L 567 QQR1277-001Z F.BEADS
L 571 QQR1277-001Z F.BEADS
Q
401 2SC3576-JVC-T TRANSISTOR
Q
402 2SC3576-JVC-T TRANSISTOR
Q
481 2SC3576-JVC-T TRANSISTOR
Q
482 2SC3576-JVC-T TRANSISTOR
Q
483 KRA102M-T D.TRANSISTOR
Q
556 2SC3576-JVC-T TRANSISTOR
Q
557 2SC3576-JVC-T TRANSISTOR
Q
562 2SC3576-JVC-T TRANSISTOR
Q
571 2SC2785/FE/-T TRANSISTOR
Q
572 2SC2785/FE/-T TRANSISTOR
Q
573 2SC2785/FE/-T TRANSISTOR
Q
585 2SC2785/FE/-T TRANSISTOR
Q
586 2SC2785/FE/-T TRANSISTOR
Q
999 KRA102M-T D.TRANSISTOR
R 401 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 402 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 403 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 404 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 405 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 406 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 407 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 411 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 412 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 413 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 414 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 426 QRE141J-560Y C RESISTOR 56 5% 1/4W
R 431 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 432 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 434 QRJ146J-4R7X UNF C RESISTOR
A
4.7 5% 1/4W
R 435 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 436 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 437 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 438 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 439 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 440 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 441 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 442 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 466 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 467 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 468 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 469 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 470 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 471 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 472 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 473 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 474 QRE141J-513Y C RESISTOR 51K 5% 1/4W
R 475 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 485 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 486 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 487 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 488 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 489 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 490 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 491 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 492 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 493 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 494 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 495 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 496 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 498 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 501 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 502 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 503 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 504 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 505 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 506 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 507 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 508 QRE141J-274Y C RESISTOR 270K 5% 1/4W
R 510 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 511 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 512 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 513 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 517 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 518 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 519 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 523 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 524 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 526 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 528 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 529 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 530 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 531 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 532 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 534 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R 536 QRE141J-113Y C RESISTOR 11K 5% 1/4W
R 537 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 541 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 557 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 558 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 560 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 562 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 563 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 564 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 571 QRE141J-271Y C RESISTOR 270 5% 1/4W
R 572 QRE141J-473Y C RESISTOR 47K 5% 1/4W
Electrical parts list (Input board)
Block No. 02
Item
Parts number Parts name Ar
e
a
Remarks
A
