3-21
CD board
Block No. [0][4][0][0]
CN860 QGF1205F1-17 CONNECTOR FFC/FPC (1-17)
CN861 QGF1205F1-17 CONNECTOR FFC/FPC (1-17)
CN880 QGF1210G1-24 CONNECTOR FFC/FPC (1-24)
CN890 QGF1205F1-24 CONNECTOR FFC/FPC (1-24)
CN911 QGD2503F1-07 CONNECTOR (1-7)
FL801 QLF0081-001 FL TUBE
FW230 QUM153-11DGZ4 FLAT WIRE
FW713 QUM153-33DGZ4 FLAT WIRE
FW915 QUM027-18Z4Z4 FLAT WIRE
J81 QNB0107-001 SPK.TERMINAL
J1001 QNS0183-001 PHONE JACK
J1021 QNS0184-001 PHONE JACK
J1022 QNS0184-001 PHONE JACK
JS956 QSW0912-001 ROTARY SW
JS960 QSW0911-001 ROTARY SW
JS962 QSW0987-001 ROTARY VR
RY1 QSK0109-001 RELAY
RY2 QSK0109-001 RELAY
S915 QSW0825-001Z TACT SW
S916 QSW0825-001Z TACT SW
S917 QSW0825-001Z TACT SW
S931 QSW0825-001Z TACT SW
S932 QSW0825-001Z TACT SW
S933 QSW0825-001Z TACT SW
S935 QSW0825-001Z TACT SW
S936 QSW0825-001Z TACT SW
S937 QSW0825-001Z TACT SW
S938 QSW0825-001Z TACT SW
S939 QSW0825-001Z TACT SW
S942 QSW0825-001Z TACT SW
S943 QSW0825-001Z TACT SW
S944 QSW0825-001Z TACT SW
S945 QSW0825-001Z TACT SW
S946 QSW0825-001Z TACT SW
S947 QSW0825-001Z TACT SW
S948 QSW0825-001Z TACT SW
S949 QSW0825-001Z TACT SW
S950 QSW0825-001Z TACT SW
S951 QSW0825-001Z TACT SW
S952 QSW0825-001Z TACT SW
S963 QSW0825-001Z TACT SW
S995 QSW0825-001Z TACT SW
S996 QSW0825-001Z TACT SW
S997 QSW0825-001Z TACT SW
S998 QSW0825-001Z TACT SW
S999 QSW0825-001Z TACT SW
SP801 VYH7653-001 IC HOLDER
X801 QAX0711-002Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
IC251 MN101C30AET1 IC CD micon
IC601 AN22000A-W IC RF & SERVO AMP
IC651 MN6627482WA IC DSP & DAC
IC801 AN4801SB-W IC
4 channel power of
amp system driver
IC851 LB1641 IC DC Motor driver
IC852 LB1641 IC DC Motor driver
Q291 2SA952/LK/-T TRANSISTOR
Q631 2SB709A/RS/-X TRANSISTOR
D851 DZ5.6BSB-T2 Z DIODE
C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C254 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C291 QERF1AM-476Z E CAPACITOR 47uF 10V M
C601 NCB31HK-222X C CAPACITOR 2200pF 50V K
C602 NCB31HK-222X C CAPACITOR 2200pF 50V K
C603 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C604 NCB31EK-223X C CAPACITOR 0.022uF 25V K
 Symbol No. Part No. Part Name Description Local
C605 NCS31HJ-331X C CAPACITOR 330pF 50V J
C606 NCS31HJ-151X C CAPACITOR 150pF 50V J
C608 NCB31HK-122X C CAPACITOR 1200pF 50V K
C610 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C612 EEKJ1HM-104ZJC E CAPACITOR
C613 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C614 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C615 NCB31HK-472X C CAPACITOR 4700pF 50V K
C616 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C617 NCS31HJ-331X C CAPACITOR 330pF 50V J
C620 NCS31HJ-560X C CAPACITOR 56pF 50V J
C621 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C622 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C623 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C624 QERF0JM-107Z E CAPACITOR 100uF 6.3V M
C631 QERF1CM-106Z E CAPACITOR 10uF 16V M
C632 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C633 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C641 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C642 NCB31HK-472X C CAPACITOR 4700pF 50V K
C651 NCS31HJ-7R0X C CAPACITOR 7pF 50V J
C652 NCS31HJ-7R0X C CAPACITOR 7pF 50V J
C653 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C655 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C657 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C658 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C659 NCB31HK-102X C CAPACITOR 1000pF 50V K
C660 NCS31HJ-331X C CAPACITOR 330pF 50V J
C661 NCS31HJ-471X C CAPACITOR 470pF 50V J
C663 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C664 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C665 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C667 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C668 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C669 QERF1AM-227Z E CAPACITOR 220uF 10V M
C672 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C676 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C677 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C679 QERF0JM-107Z E CAPACITOR 100uF 6.3V M
C680 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C801 NCB31HK-682X C CAPACITOR 6800pF 50V K
C802 NCB31HK-392X C CAPACITOR 3900pF 50V K
C811 NCS31HJ-220X C CAPACITOR 22pF 50V J
C812 NCS31HJ-220X C CAPACITOR 22pF 50V J
C813 NCS31HJ-220X C CAPACITOR 22pF 50V J
C814 NCS31HJ-220X C CAPACITOR 22pF 50V J
C821 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C822 QERF1AM-227Z E CAPACITOR 220uF 10V M
C852 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C853 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C854 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C855 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C859 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C860 NCF31AZ-105X C CAPACITOR 1uF 10V Z
R252 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R254 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R255 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R256 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R257 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R258 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R259 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R261 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R262 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R263 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R291 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R292 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R293 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R294 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R601 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R602 NRSA63J-274X MG RESISTOR 270k
Ω 1/16W J
R603 NRSA63J-513X MG RESISTOR 51k Ω 1/16W J
R604 NRSA63J-114X MG RESISTOR 110k
Ω 1/16W J
R606 NRSA63J-623X MG RESISTOR 62k
Ω 1/16W J
R607 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R608 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
