JVC MX-GA9V User Manual

3-22
VCD board
Block No. [0][5][0][0]
R611 NRSA63J-512X MG RESISTOR 5.1k Ω 1/16W J
R613 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R614 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R622 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R623 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R624 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R625 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R626 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R627 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R628 NRSA63J-225X MG RESISTOR 2.2M Ω 1/16W J
R631 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R632 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R634 NRSA63J-120X MG RESISTOR 12 Ω 1/16W J
R635 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R641 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R642 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R647 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R648 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R649 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R650 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R651 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R652 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R653 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R654 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R656 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R657 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R658 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R659 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R660 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R661 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R662 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R663 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R664 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R665 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R667 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R668 NRSA63J-155X MG RESISTOR 1.5M Ω 1/16W J
R669 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R670 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R672 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R677 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R678 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R679 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R682 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R683 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R684 NRSA63J-564X MG RESISTOR 560k Ω 1/16W J
R685 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R801 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R802 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R803 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R804 NRSA63J-434X MG RESISTOR 430k
Ω 1/16W J
R805 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R806 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
R807 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R808 NRSA63J-913X MG RESISTOR 91k Ω 1/16W J
R810 NRSA63J-433X MG RESISTOR 43k
Ω 1/16W J
R811 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R831 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R832 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R851 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R852 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R853 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R854 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R861 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R862 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R863 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R864 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R865 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R866 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R871 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R872 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R873 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R874 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R875 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R876 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R880 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R881 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R882 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R883 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R884 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R885 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R886 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R887 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R888 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R889 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R890 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R891 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R892 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R893 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R894 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R895 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
CN151 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN601 QGF1016F3-16 CONNECTOR FFC/FPC (1-16)
CN651 QGF1036F1-19 CONNECTOR FFC/FPC (1-19)
CN801 QGA2001C1-06 CONNECTOR W-B (1-6)
CN854 QGB2016K1-07 CONNECTOR B-B (1-7)
CN855 QGG2002M4-10 CONNECTOR (1-10)
W601 QUB220-07HPDT SIN TWIST WIRE
X251 QAX0246-001Z C RESONATOR 8.00MHz
X651 QAX0750-001Z CRYSTAL 16.9344MHz
 Symbol No. Part No. Part Name Description Local
IC101 ES3880FM IC
Video CD
processor
IC102 AT27C020-70JC6 IC
OTP EPROM 2M
bit
IC103 GLT44016-35J4-X IC (4M DRAM) Dram
IC103 M11B416256A-30J DRAM IC
IC103 M11B416256A-35J DRAM IC
IC104 ES3883F IC
VCD Companion
chip
IC105 RT9161/A-27CG-X IC
IC106 TC7S08F-W IC Buffer
IC107 TC7W08FU-X IC Nand gate
C101 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C102 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C103 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C104 QERF1CM-106Z E CAPACITOR 10uF 16V M
C105 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C106 QERF1CM-106Z E CAPACITOR 10uF 16V M
C107 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C109 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C110 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C111 NCS31HJ-471X C CAPACITOR 470pF 50V J
C112 NCS31HJ-471X C CAPACITOR 470pF 50V J
C113 NCS31HJ-220X C CAPACITOR 22pF 50V J
C114 NCB31HK-102X C CAPACITOR 1000pF 50V K
C115 NCS31HJ-220X C CAPACITOR 22pF 50V J
C116 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C117 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C118 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C120 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C121 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C122 QERF1AM-107Z E CAPACITOR 100uF 10V M
C123 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C124 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C125 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C126 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C127 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C128 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C129 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C130 QERF1AM-107Z E CAPACITOR 100uF 10V M
C131 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C132 QERF1AM-107Z E CAPACITOR 100uF 10V M
C133 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C134 QERF1CM-106Z E CAPACITOR 10uF 16V M
C135 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C136 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
 Symbol No. Part No. Part Name Description Local
