Tuner board
Block No. [0][6][0][0]
C137 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C138 QERF1AM-107Z E CAPACITOR 100uF 10V M
C140 NCS31HJ-220X C CAPACITOR 22pF 50V J
C141 NCS31HJ-220X C CAPACITOR 22pF 50V J
R101 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R102 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R103 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R104 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R105 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R106 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R107 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R108 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R109 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R111 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R112 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R113 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R119 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R120 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R121 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R128 NRSA63J-330X MG RESISTOR 33
Ω 1/16W J
R130 NQR0022-002X FERRITE BEADS
R132 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R133 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R134 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R135 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R136 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R137 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R138 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R139 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R140 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R141 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R142 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R145 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R146 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R147 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R148 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
L101 NQL591K-3R3X INDUCTOR 3.3uH K
L102 NQL591K-3R3X INDUCTOR 3.3uH K
CN101 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN102 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
K101 NQR0398-006X FERRITE BEADS
K102 NQR0398-006X FERRITE BEADS
K103 NRSA02J-180X MG RESISTOR 18 Ω 1/10W J
K104 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
X101 QAX0700-001Z CRYSTAL 27.000000MHz
 Symbol No. Part No. Part Name Description Local
IC1 LA1838 IC
FM AM IF
AMP&detector FM
MPX Decoder
IC2 LC72136N IC
PLL frequency
synthesizer
Q1 2SC2814/4-5/-X TRANSISTOR
Q5 KRA107S-X DIGI TRANSISTOR
D1 1SS133-T2 DIODE
D2 1SS133-T2 DIODE
D3 1SS133-T2 DIODE
D4 1SS133-T2 DIODE
D11 1SS133-T2 DIODE
C1 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C2 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C3 EETC1CM-106ZJC E CAPACITOR
C4 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C6 NCB21HK-102X C CAPACITOR 1000pF 50V K
C7 NCB21HK-102X C CAPACITOR 1000pF 50V K
 Symbol No. Part No. Part Name Description Local
C8 NCB21HK-102X C CAPACITOR 1000pF 50V K
C10 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
C11 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C12 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C13 NCS21HJ-100X C CAPACITOR 10pF 50V J
C14 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C15 NCS21HJ-120X C CAPACITOR 12pF 50V J
C16 NCS21HJ-120X C CAPACITOR 12pF 50V J
C17 NCB21HK-392X C CAPACITOR 3900pF 50V K
C18 QEQ61HM-474Z E CAPACITOR 0.47uF 50V M
C19 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C20 NCB21HK-102X C CAPACITOR 1000pF 50V K
C21 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C22 NCS21HJ-151X C CAPACITOR 150pF 50V J
C23 NCS21HJ-151X C CAPACITOR 150pF 50V J
C24 NCS21HJ-151X C CAPACITOR 150pF 50V J
C25 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C26 NCB21HK-102X C CAPACITOR 1000pF 50V K
C27 NCB21HK-102X C CAPACITOR 1000pF 50V K
C30 EEKC1CM-107ZJC E CAPACITOR
C31 EEKC1CM-226ZJC E CAPACITOR
C32 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C33 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C34 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C35 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C36 EEKC1HM-105ZJC E CAPACITOR
C37 EEKC1HM-105ZJC E CAPACITOR
C38 EETC1HM-224ZJC E CAPACITOR
C39 EETC1HM-105ZJC E CAPACITOR
C40 QETN1CM-106Z E CAPACITOR 10uF 16V M
C41 QETN1CM-106Z E CAPACITOR 10uF 16V M
C42 NCB21HK-152X C CAPACITOR 1500pF 50V K
C43 NCB21HK-152X C CAPACITOR 1500pF 50V K
C44 QETN1CM-106Z E CAPACITOR 10uF 16V M
C45 QETN1CM-106Z E CAPACITOR 10uF 16V M
C46 NCB21HK-273X C CAPACITOR 0.027uF 50V K
C47 EETC1HM-105ZJC E CAPACITOR
C48 NCB21HK-222X C CAPACITOR 2200pF 50V K
C49 NCS21HJ-471X C CAPACITOR 470pF 50V J
C50 EEKC1CM-226ZJC E CAPACITOR
C51 EEKC1HM-105ZJC E CAPACITOR
C52 QFVJ1HJ-274Z MF CAPACITOR 0.27uF 50V J
C53 EETC1CM-226ZJC E CAPACITOR
C54 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C57 NCB21HK-102X C CAPACITOR 1000pF 50V K
C58 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C59 NCB21HK-102X C CAPACITOR 1000pF 50V K
R1 QRE141J-560Y C RESISTOR 56 Ω 1/4W J
R2 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R3 NRSA02J-224X MG RESISTOR 220k Ω 1/10W J
R4 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R5 NRSA02J-560X MG RESISTOR 56
Ω 1/10W J
R6 NRSA02J-240X MG RESISTOR 24 Ω 1/10W J
R10 NRSA02J-222X MG RESISTOR 2.2k
Ω 1/10W J
R13 NRSA02J-103X MG RESISTOR 10k
Ω 1/10W J
R14 NRSA02J-104X MG RESISTOR 100k Ω 1/10W J
R15 NRSA02J-332X MG RESISTOR 3.3k
Ω 1/10W J
R16 NRSA02J-472X MG RESISTOR 4.7k Ω 1/10W J
 R17 QRZ9005-680X F RESISTOR 68 Ω
R18 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
R19 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
R20 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R21 NRSA02J-562X MG RESISTOR 5.6k
Ω 1/10W J
R22 NRSA02J-472X MG RESISTOR 4.7k Ω 1/10W J
R23 NRSA02J-182X MG RESISTOR 1.8k
Ω 1/10W J
R24 NRSA02J-103X MG RESISTOR 10k
Ω 1/10W J
R25 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R26 NRSA02J-222X MG RESISTOR 2.2k
Ω 1/10W J
R27 NRSA02J-103X MG RESISTOR 10k Ω 1/10W J
R28 NRSA02J-103X MG RESISTOR 10k
Ω 1/10W J
R29 NRSA02J-103X MG RESISTOR 10k
Ω 1/10W J
R30 NRSA02J-122X MG RESISTOR 1.2k Ω 1/10W J
R31 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R32 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R33 NRSA02J-331X MG RESISTOR 330 Ω 1/10W J
R34 NRSA02J-470X MG RESISTOR 47
Ω 1/10W J
R35 NRSA02J-562X MG RESISTOR 5.6k
Ω 1/10W J
 Symbol No. Part No. Part Name Description Local
