3-24
CD switch board
Block No. [0][7][0][0]
Head amplifier &
mechanism control board
Block No. [0][8][0][0]
R36 NRSA02J-332X MG RESISTOR 3.3k Ω 1/10W J
R37 NRSA02J-103X MG RESISTOR 10k Ω 1/10W J
R38 NRSA02J-563X MG RESISTOR 56k Ω 1/10W J
R39 NRSA02J-563X MG RESISTOR 56k Ω 1/10W J
R40 NRSA02J-243X MG RESISTOR 24k Ω 1/10W J
R41 NRSA02J-332X MG RESISTOR 3.3k
Ω 1/10W J
R60 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L1 QQR0796-003 COIL BLOCK
T1 QQR0793-001 IFT
CF1 QAX0677-001Z C FILTER 10.700MHz
CF2 QAX0677-001Z C FILTER 10.700MHz
CF3 QAX0610-001Z C DISCRIMINATOR 10.700MHz
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
J1 QNB0014-001 ANT.TERMINAL
TU1 QAU0161-001 FRONT END
X1 QAX0402-001 CRYSTAL 75.0kHz
 Symbol No. Part No. Part Name Description Local
CN804 QGB2016J1-07 CONNECTOR B-B (1-7)
CN805 QGB2021L1-10 CONNECTOR B-B (1-10)
SW1 QSW0859-001 LEVER SWITCH
SW2 QSW0859-001 LEVER SWITCH
SW3 QSW0859-001 LEVER SWITCH
SW4 QSW0859-001 LEVER SWITCH
SW5 QSW0859-001 LEVER SWITCH
SW6 QSW0859-001 LEVER SWITCH
 Symbol No. Part No. Part Name Description Local
IC301 BA3126N IC R/P Switch
IC302 AN7345K IC PB/REC AMP
IC303 CD4094BC IC
Serial to parallel
port extension
IC331 SG-105F3-BB,C PHOTO SENSER
IC332 SG-105F3-BB,C PHOTO SENSER
Q3105 2SC3576-JVC-T TRANSISTOR
Q3205 2SC3576-JVC-T TRANSISTOR
Q3302 2SC2001/K/-T TRANSISTOR
Q3305 2SC2001/K/-T TRANSISTOR
Q3312 2SB562/C/-T TRANSISTOR
Q3313 KTC3199/GL/-T TRANSISTOR
Q3314 2SB562/C/-T TRANSISTOR
Q3315 KTC3199/GL/-T TRANSISTOR
Q3316 KTA1267/YG/-T TRANSISTOR
Q3317 KRC107M-T DIGI TRANSISTOR
Q3323 KRC104M-T TRANSISTOR
Q3324 KRA102M-T DIGI TRANSISTOR
D3302 1SR139-400-T2 SI DIODE
D3307 DZ5.1BSB-T2 Z DIODE
D3308 DZ5.1BSB-T2 Z DIODE
D3309 DZ5.1BSB-T2 Z DIODE
D3331 1SR139-400-T2 SI DIODE
C3101 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C3102 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C3103 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C3104 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
 Symbol No. Part No. Part Name Description Local
C3105 EEKJ1AM-107ZJC E CAPACITOR
C3107 EEKJ1HM-105ZJC E CAPACITOR 1uF 50V M
C3111 EEKJ1HM-104ZJC E CAPACITOR
C3112 EEKJ1CM-106ZJC E CAPACITOR
C3113 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C3114 EEKJ1EM-475ZJC E CAPACITOR
C3115 QFLK1HJ-153Z M CAPACITOR 0.015uF 50V J
C3116 QDYB1CM-822Y C CAPACITOR 8200pF 16V M
C3119 QFLM1HJ-563Z M CAPACITOR 0.056uF 50V J
C3120 QCSB1HJ-330Y C CAPACITOR 33pF 50V J
C3121 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C3201 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C3202 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C3203 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C3204 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C3205 EEKJ1AM-107ZJC E CAPACITOR
C3206 QFLK1HJ-333Z M CAPACITOR 0.033uF 50V J
C3207 EEKJ1HM-105ZJC E CAPACITOR 1uF 50V M
C3211 EEKJ1HM-104ZJC E CAPACITOR
C3212 EEKJ1CM-106ZJC E CAPACITOR
C3213 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C3214 EEKJ1EM-475ZJC E CAPACITOR
C3215 QFLK1HJ-153Z M CAPACITOR 0.015uF 50V J
C3216 QDYB1CM-822Y C CAPACITOR 8200pF 16V M
C3219 QFLM1HJ-563Z M CAPACITOR 0.056uF 50V J
C3220 QCSB1HJ-330Y C CAPACITOR 33pF 50V J
C3221 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C3222 QFLK1HJ-333Z M CAPACITOR 0.033uF 50V J
C3301 EEKJ1AM-107ZJC E CAPACITOR
C3302 EEKJ1AM-107ZJC E CAPACITOR
C3303 EEKJ1CM-226ZJC E CAPACITOR
C3304 EEKJ1EM-475ZJC E CAPACITOR
C3305 QFLK1HJ-393Z M CAPACITOR 0.039uF 50V J
C3306 EEKJ0JM-227ZJC E CAPACITOR
C3308 QDXB1CM-152Y C CAPACITOR 1500pF 16V M
C3313 EEKJ1AM-107ZJC E CAPACITOR
C3314 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C3315 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C3316 QFG32AJ-103Z PP CAPACITOR 0.01uF 100V J
C3327 EEKJ1CM-476ZJC E CAPACITOR
C3335 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C3336 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C3339 EEKJ1CM-476ZJC E CAPACITOR
C3340 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C3341 EEKJ1AM-107ZJC E CAPACITOR
C3342 EEKJ1EM-475ZJC E CAPACITOR
C3345 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C3350 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C3501 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C3502 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C3555 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C3601 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C3602 QCBB1HK-271Y C CAPACITOR 270pF 50V K
R3103 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R3105 QRE141J-220Y C RESISTOR 22
Ω 1/4W J
R3106 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R3107 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R3108 QRE141J-241Y C RESISTOR 240 Ω 1/4W J
R3111 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R3112 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R3113 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R3114 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R3117 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R3118 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R3119 QRE141J-203Y C RESISTOR 20k
Ω 1/4W J
R3120 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R3121 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R3203 QRE141J-183Y C RESISTOR 18k
Ω 1/4W J
R3205 QRE141J-220Y C RESISTOR 22 Ω 1/4W J
R3206 QRE141J-392Y C RESISTOR 3.9k
Ω 1/4W J
R3207 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R3208 QRE141J-241Y C RESISTOR 240 Ω 1/4W J
R3211 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R3212 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R3213 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R3214 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R3217 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
