JVC MX-GA9V User Manual

3-25
R3218 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R3219 QRE141J-203Y C RESISTOR 20k Ω 1/4W J
R3220 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R3221 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
R3301 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R3302 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R3304 QRE141J-393Y C RESISTOR 39k
Ω 1/4W J
R3309 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R3311 QRJ146J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R3314 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R3315 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R3327 QRE141J-474Y C RESISTOR 470k Ω 1/4W J
R3330 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3331 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3335 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R3336 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R3344 QRE141J-224Y C RESISTOR 220k Ω 1/4W J
R3345 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R3347 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R3348 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R3350 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R3351 QRE141J-151Y C RESISTOR 150
Ω 1/4W J
R3353 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R3354 QRE141J-151Y C RESISTOR 150 Ω 1/4W J
R3355 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R3359 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3361 QRE141J-393Y C RESISTOR 39k Ω 1/4W J
R3362 QRE141J-243Y C RESISTOR 24k Ω 1/4W J
R3366 QRE141J-273Y C RESISTOR 27k Ω 1/4W J
R3367 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3368 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R3369 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R3370 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3374 QRE141J-2R2Y C RESISTOR 2.2 Ω 1/4W J
 R3376 QRZ9005-100X FUSI RESISTOR 10 Ω
R3377 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R3378 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R3379 QRE141J-203Y C RESISTOR 20k Ω 1/4W J
R3380 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R3381 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
R3383 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
VR101 QVP0008-503Z TRIM RESISTOR 50k Ω
VR201 QVP0008-503Z TRIM RESISTOR 50k Ω
VR301 QVP0008-103Z TRIM RESISTOR 10k Ω
L3202 QQR0621-001Z COIL
L3301 QQR1118-002 OSC COIL(BIAS)
L3303 QQL244K-100Z COIL 10uH K
CN301 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
CN302 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
CN303 QGB2011M1-10 CONNECTOR B-B (1-10)
CN305 QGF1201F3-10 CONNECTOR FFC/FPC (1-10)
CN306 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN333 QGB2011L1-10 CONNECTOR B-B (1-10)
FW301 EWR34D-10CS FLAT WIRE
P3302 QNZ0104-001 POST PIN
P3331 QNZ0104-001 POST PIN
SW302 QSW0832-001 CASS.SWITCH
SW303 QSW0832-001 CASS.SWITCH
SW304 QSW0832-001 CASS.SWITCH
SW305 QSW0832-001 CASS.SWITCH
SW306 QSW0859-001 DETECT SWITCH
SW316 QSW0859-001 DETECT SWITCH
W3301 QUB230-06HPHP WIRE ASSY
 Symbol No. Part No. Part Name Description Local
