MX-GT80/MX-GT90
1-36
BA3126N(IC301) : R/P Switch
R E C
S W
G
123456789
P / B
S W
P / B
S W
G
R E C
S W
C O N T .
G N D
V c c
1 2 3 4 5 6 7 8 9
10
GND OUT1 P1
VZ IN1 IN2
VCC1
VCC2 P2
OUT2
Input Output
Mode
IN1 IN2 OUT1 OUT2
Brake
0 0 0 0
1 0 1 0
0 1 0 1
1 1 0 0
CLOCKWISE
COUNTER-CLOCKWISE
Brake
LB1641 (IC851,IC852) : DC motor driver
1. Pin layout
2. Pin function
