MX-GT91R
3-15
Item
Parts number Parts name Area
Remarks
A
R 769 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 774 QRJ146J-100X UNF.C RESISTOR
A
10 5% 1/4W
R 775 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 776 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 777 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 778 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 786 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 787 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 790 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 792 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 793 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 794 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 795 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 796 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 797 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 798 QRJ146J-100X UNF.C RESISTOR
A
10 5% 1/4W
R 904 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 908 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
S 901 QSW0674-001Z TACT SWITCH
S 902 QSW0674-001Z TACT SWITCH
Electrical parts list (Regulator & amplifier board)
Block No. 01
