MX-GT91R

3-16

Item

Parts number Parts name Area

Remarks

C 250 QETC1EM-226Z CAPACITOR 22MF 20% 25V

C 251 EETC1CM-477ZJC E CAPACITOR

C 252 QCZ9104-472 C CAPACITOR 4700PF

C 253 QFLM1HJ-472Z M CAPACITOR 4700PF 5% 50V

C 401 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 402 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 403 FQCF31HP-103Z D CAPACITOR

C 404 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 405 QDGB1HK-102Y C CAPACITOR

C 406 QDGB1HK-102Y C CAPACITOR

C 411 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 412 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 415 QDXB1CM-222Y C CAPACITOR

C 426 QDVB1EZ-223Y C CAPACITOR

C 427 EETC1EM-106ZJC E CAPACITOR

C 432 FQCF31HP-103Z D CAPACITOR

C 433 FQCF31HP-103Z D CAPACITOR

C 436 EETC1AM-107ZJC E CAPACITOR

C 437 EETC1EM-106ZJC E CAPACITOR

C 438 QDYB1CM-103Y C CAPACITOR

C 439 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 440 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 441 QTE1V06-106Z E CAPACITOR

C 442 QTE1V06-106Z E CAPACITOR

C 443 EETC1HM-225ZJC E CAPACITOR

C 444 EETC1HM-225ZJC E CAPACITOR

C 445 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 446 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 447 QETN1CM-106Z E CAPACITOR 10MF 20% 16V

C 448 QETN1CM-106Z E CAPACITOR 10MF 20% 16V

C 453 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 454 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 455 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V

C 456 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V

C 457 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 458 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 459 QFLM1HJ-183Z M CAPACITOR .018MF 5% 50V

C 460 QFLM1HJ-183Z M CAPACITOR .018MF 5% 50V

C 461 QFLM1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 462 QFLM1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 481 QFLM1HJ-273Z M CAPACITOR .027MF 5% 50V

C 482 QFLM1HJ-273Z M CAPACITOR .027MF 5% 50V

C 483 QFLM1HJ-273Z M CAPACITOR .027MF 5% 50V

C 484 QFLM1HJ-273Z M CAPACITOR .027MF 5% 50V

C 485 QTE1V06-106Z E CAPACITOR

C 486 QTE1V06-106Z E CAPACITOR

C 487 EETC1AM-107ZJC E CAPACITOR

C 488 EETC1HM-105ZJC E CAPACITOR

C 489 EETC1AM-107ZJC E CAPACITOR

C 501 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 502 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 503 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 504 QFLM1HJ-822Z M CAPACITOR 8200PF 5% 50V

C 505 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V

C 507 QFLM1HJ-153Z M CAPACITOR .015MF 5% 50V

C 508 QFLM1HJ-273Z M CAPACITOR .027MF 5% 50V

C 509 QETN1CM-106Z E CAPACITOR 10MF 20% 16V

C 510 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 514 QFLC1HJ-471Z M CAPACITOR 470PF 5% 50V

C 526 EETC1AM-107ZJC E CAPACITOR

C 527 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V

C 528 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 530 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 531 QFVJ1HJ-334Z MF CAPACITOR .33MF 5% 50V

C 532 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 534 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 535 EETC1AM-107ZJC E CAPACITOR

C 556 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 571 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 575 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C 576 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 577 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 578 EETC1HM-105ZJC E CAPACITOR

C 585 EETC1HM-105ZJC E CAPACITOR

C 586 QDXB1CM-182Y C CAPACITOR

C 587 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V

C 588 QDGB1HK-681Y C CAPACITOR

C 589 QFLM1HJ-153Z M CAPACITOR .015MF 5% 50V

C 886 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 887 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%

C 888 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 889 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%

C 993 QDYB1CM-103Y C CAPACITOR

C 995 EETC1AM-107ZJC E CAPACITOR

C 996 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V

C 997 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V

C 998 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C 999 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

CN 11 QGF1205F1-13 CONNECTOR

CN209 WJK0070-002A WIRE

CN211 QGB2510K2-09 CONNECTOR

CN212 QGB2510K2-08 CONNECTOR

CN213 QGB2510K2-04 CONNECTOR

CN214 QJK015-071214 SKT WIRE

CN218 QGA7901F2-02 CONNECTOR

CN220 QGD2504C1-03Z SOCKET

CN250 QGA7901C1-02 CONNECTOR

CN315 QGF1205C1-10 CONNECTOR

CN661 QGF1016F3-19 CONNECTOR

CN870 QGF1205C1-17 CONNECTOR

CN871 QGF1205C1-17 CONNECTOR

C1201 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C1202 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V

C1205 FQCF31HP-103Z D CAPACITOR

C1206 FQCF31HP-223Z D CAPACITOR

C1207 FQCF31HP-103Z D CAPACITOR

C1228 EETC1AM-107ZJC E CAPACITOR

D 252 1N4003S-T5 SI DIODE

D 254 1SS133-T2 SI DIODE

D 255 1SS133-T2 SI DIODE

D 256 MTZJ6.2A-T2 Z.DIODE

D 411 1SS133-T2 SI DIODE

D 412 1SS133-T2 SI DIODE

D 426 MTZJ5.1B-T2 ZENER DIODE

D 431 MTZJ3.9B-T2 ZENER DIODE

D 432 MTZJ3.9B-T2 ZENER DIODE

D 434 MTZJ5.1B-T2 ZENER DIODE

D 501 1SS133-T2 SI DIODE

D 502 1SS133-T2 SI DIODE

D 571 1SS133-T2 SI DIODE

D 572 1SS133-T2 SI DIODE

D 585 1SS133-T2 SI DIODE

D 592 1SS133-T2 SI DIODE

EP250 E409182-001SM GRAND TERMINAL

FT111 QNG0020-001Z FUSE CLIP

FT112 QNG0020-001Z FUSE CLIP

Electrical parts list (Main board)

Block No. 02

Item

Parts number Parts name Area

Remarks
