JVC MX-GT91R - Page 75

MX-GT91R
3-18
Item
Parts number Parts name Area
Remarks
A
C 233 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C 308 EETC1HM-106ZJC E CAPACITOR
C 310 EETC1HM-106ZJC E CAPACITOR
C 312 EETC1HM-106ZJC E CAPACITOR
C 360 EETC1CM-476ZJC E CAPACITOR
C 361 QDYB1CM-103Y C CAPACITOR
C 362 EETC1HM-226ZJC E CAPACITOR
C 651 QDXB1CM-222Y C CAPACITOR
C 652 QDXB1CM-222Y C CAPACITOR
C 653 FQCF31HP-473Z TF CAPACITOR
C 654 FQCF31HP-473Z TF CAPACITOR
C 732 FQCF31HP-473Z TF CAPACITOR
C 733 FQCF31HP-473Z TF CAPACITOR
C 734 QDXB1CM-222Y C CAPACITOR
C 735 QDXB1CM-222Y C CAPACITOR
C 801 FQCF31HP-103Z D CAPACITOR
C 803 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 804 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 805 QDGB1HK-102Y C CAPACITOR
C 808 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V
C 809 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V
C 815 EETC1HM-226ZJC E CAPACITOR
C 816 EETC1CM-476ZJC E CAPACITOR
C 817 EETC1HM-226ZJC E CAPACITOR
C 820 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 821 QDYB1CM-103Y C CAPACITOR
C 823 QFVJ1HJ-334Z M CAPACITOR .33MF 5% 50V
C 825 QDGB1HK-102Y C CAPACITOR
C 831 QDYB1CM-103Y C CAPACITOR
C 832 QDYB1CM-103Y C CAPACITOR
C 835 QDGB1HK-102Y C CAPACITOR
C 836 EETC1EM-106ZJC E CAPACITOR
C 837 EETC1AM-107ZJC E CAPACITOR
C 838 QDGB1HK-102Y C CAPACITOR
C 840 EETC1HM-225ZJC E CAPACITOR
C 857 EETC1HM-226ZJC E CAPACITOR
C 872 EETC1HM-224ZJC E CAPACITOR
C 873 EETC1HM-224ZJC E CAPACITOR
C 874 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C 875 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C 889 EETC1HM-475ZJC E CAPACITOR
C 935 QDYB1CM-103Y C CAPACITOR
C 956 QDYB1CM-103Y C CAPACITOR
C 957 QDYB1CM-103Y C CAPACITOR
C 960 QDYB1CM-103Y C CAPACITOR
C 961 QDYB1CM-103Y C CAPACITOR
C 962 QDYB1CM-103Y C CAPACITOR
C 963 QDYB1CM-103Y C CAPACITOR
CN216 QGB2510K2-10 CONNECTOR
CN217 QGB2510K2-10 CONNECTOR
CN316 QGF1210G1-09 CONNECTOR
CN860 QGF1205F1-17 CONNECTOR
CN861 QGF1205F1-17 CONNECTOR
CN880 QGF1210G1-22 FFC SOCKET ASSY
CN890 QGF1205F1-22 CONECTOR
CN911 QGD2503F1-07 SOCKET
C1001 QDXB1CM-392Y C CAPACITOR
C1002 QDXB1CM-392Y C CAPACITOR
C1004 QDGB1HK-102Y C CAPACITOR
C1070 QDXB1CM-222Y C CAPACITOR
D 313 MTZJ8.2B-T2 DIODE
D 314 MTZJ13B-T2 Z DIODE
D 315 MTZJ9.1B-T2 ZENER DIODE
D 360 MTZJ5.1B-T2 ZENER DIODE
D 361 MTZJ11C-T2 Z DIODE
D 362 MTZJ6.8C-T2 Z DIODE
D 650 1SS133-T2 SI DIODE
D 725 1SS133-T2 SI DIODE
D 801 1N4003S-T5 SI DIODE
D 802 1SS133-T2 SI DIODE
D 803 1SS119-02-T2 SI DIODE
D 804 1SS133-T2 SI DIODE
D 805 1SS133-T2 SI DIODE
D 806 1SS119-02-T2 SI DIODE
D 807 1N4003S-T5 SI DIODE
D 812 1SS133-T2 SI DIODE
D 815 MTZJ6.2C-T2 Z DIODE
D 816 MTZJ6.2C-T2 Z DIODE
D 831 MTZJ5.1B-T2 ZENER DIODE
D 832 MTZJ5.1B-T2 ZENER DIODE
D 918 SLA-362LT-T LED
D 919 SLA-362LT-T LED
D 920 SLA-362LT-T LED
D 940 L-914SRD-T LED
D 941 L-914SRD-T LED
D 942 L-914SRD-T LED
D 943 L-914SRD-T LED
D 944 L-914SRD-T LED
D 945 L-914SRD-T LED
D 953 L-914SRD-T LED
D 954 L-914SRD-T LED
D 956 SLA-362LT-T LED
D 957 SLA-362LT-T LED
D 960 SLA-362LT-T LED
D 961 SLA-362LT-T LED
D 962 SLA-362LT-T LED
D 964 1SS133-T2 SI DIODE
D1003 MTZJ2.4B-T2 Z.DIODE
FL801 QLF0081-001 FL TUBE
FW230 QUM153-11DGZ4 FLAT WIRE
FW713 QUM023-33DGZ4 FLAT WIRE
FW915 QUM027-18Z4Z4 FLAT WIRE
IC303 KIA7808API IC
A
IC304 KIA7812API IC
A
IC305 KIA7809API IC
A
IC810 MN101C35DEC2 IC
IC811 BU2092 IC
IC812 BA3835S IC
IC830 KIA7042AP-T IC
IC951 GP1U271X RM RECIVER
J 81 QNB0107-001 SPK.TERMINAL
JS956 QSW0912-001 ROTALY SWITCH S/WOOFER VOL
JS960 QSW0911-001 ROTALY SWITCH S/MODE VOL
JS962 QSW0862-001 ROTALY SWITCH MAIN VOL
J1001 QNS0183-001 PHONE JACK HEAD PHONE
L 801 QQL29BJ-100Z INDUCTOR
L 802 QQL231K-220Y INDUCTOR
L 803 QQL29BJ-100Z INDUCTOR
L 805 QQL29BJ-100Z INDUCTOR
L 806 QQL29BJ-100Z INDUCTOR
L 813 QQR0779-001Z INDUCTOR
L1001 QQL231K-470Y INDUCTOR
L1002 QQL231K-470Y INDUCTOR
L1003 QQR0779-001Z INDUCTOR
Q
360 2SD2395/EF/ TRANSISTOR
A
Q
361 KTC3199/GL/-T TRANSISTOR
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Area
Remarks
A
