MX-GT91R
3-19
Item
Parts number Parts name Area
Remarks
A
Q
362 KTC3199/GL/-T TRANSISTOR
Q
802 KRC102M TRANSISTOR
Q
809 2SD1991A/RS/-T TRANSISTOR
Q
810 2SD1991A/RS/-T TRANSISTOR
Q
811 2SD1991A/RS/-T TRANSISTOR
Q
812 2SD1991A/RS/-T TRANSISTOR
Q
813 2SD1991A/RS/-T TRANSISTOR
Q
816 2SD1991A/RS/-T TRANSISTOR
Q
817 2SD1991A/RS/-T TRANSISTOR
Q
843 KRA102M-T D.TRANSISTOR
Q
858 2SD1991A/RS/-T TRANSISTOR
Q
875 KRC102M-T D.TRANSISTOR
Q
877 KRA102M-T D.TRANSISTOR
Q
878 KRC102M-T D.TRANSISTOR
Q
879 2SD1991A/RS/-T TRANSISTOR
Q
890 2SD1991A/RS/-T TRANSISTOR
Q
905 KRC104M-T D.TRANSISTOR
Q
906 KRC104M-T D.TRANSISTOR
Q
907 KRC102M-T D.TRANSISTOR
Q
908 KRA102M-T D.TRANSISTOR
Q
918 KRC102M-T D.TRANSISTOR
Q
919 KRC102M-T D.TRANSISTOR
Q
920 KRC102M-T D.TRANSISTOR
Q
940 KTA1267/YG/-T TRANSISTOR
Q
941 KTA1267/YG/-T TRANSISTOR
Q
953 KTA1267/YG/-T TRANSISTOR
Q
954 KTA1267/YG/-T TRANSISTOR
Q
956 KTA1267/YG/-T TRANSISTOR
Q
960 KTA1267/YG/-T TRANSISTOR
Q
961 KRA102M-T D.TRANSISTOR
R 151 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 233 QRK126J-470X C RESISTOR 47 5% 1/2W
R 234 QRK126J-470X C RESISTOR 47 5% 1/2W
R 302 QRJ146J-2R2X UNF C.RESISTOR
A
2.2 5% 1/4W
R 306 ERX12SJR33E C RESISTOR
A
R 360 QRZ9042-2R2X F RESISTOR
A
2.2 1/0W
R 361 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R 362 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 363 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 364 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 365 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 366 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 367 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 368 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 650 QRJ146J-4R7X UNF C.RESISTOR 4.7 5% 1/4W
R 651 QRJ146J-4R7X UNF C.RESISTOR 4.7 5% 1/4W
R 731 QRJ146J-4R7X UNF C.RESISTOR 4.7 5% 1/4W
R 732 QRJ146J-4R7X UNF C.RESISTOR 4.7 5% 1/4W
R 801 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 807 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 808 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 810 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 811 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 812 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 813 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 814 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 815 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 816 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 817 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 818 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 819 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 820 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 821 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 822 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 823 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 824 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 825 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 826 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 827 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 828 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 829 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 831 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 832 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 833 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 834 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 835 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 836 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 837 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 838 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 839 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 840 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 841 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 842 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 843 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 844 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 845 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 846 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 847 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 848 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 849 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 850 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 851 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 854 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 855 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 856 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 857 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 858 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 859 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 865 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 866 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 867 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 868 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 869 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 870 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 871 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 872 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 873 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 874 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 876 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 877 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 878 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 879 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 880 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 881 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 882 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 883 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 884 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 885 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 886 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 887 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 888 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 889 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 890 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 891 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 893 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 894 QRE141J-334Y C RESISTOR 330K 5% 1/4W
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Area
Remarks
A
