MX-GT91R
3-20
Item
Parts number Parts name Area
Remarks
A
R 895 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 897 QRE141J-334Y C RESISTOR 330K 5% 1/4W
R 902 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 905 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 906 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 911 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 912 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 916 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 917 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 918 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 919 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 920 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 921 QRE141J-753Y C RESISTOR 75K 5% 1/4W
R 930 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 931 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 932 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 933 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 935 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 936 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 937 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 938 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 939 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 940 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 941 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 942 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 943 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 944 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 945 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 946 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 947 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 948 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 949 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 950 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 952 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 953 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 954 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 955 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 956 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 960 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 961 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 962 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 963 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 964 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 965 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 969 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 970 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 980 QRE141J-100Y C RESISTOR 10 5% 1/4W
R 991 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 992 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 993 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 994 QRE141J-753Y C RESISTOR 75K 5% 1/4W
R 995 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 996 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 997 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 998 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
RA801 QRB169J-104 R.NETWORK 100K 5% 1/6W
RA802 QRB169J-104 R.NETWORK 100K 5% 1/6W
RY 1 QSK0109-001 RELAY
RY 2 QSK0109-001 RELAY
S 915 QSW0674-001Z TACT SWITCH DISC 1
S 916 QSW0674-001Z TACT SWITCH
S 917 QSW0674-001Z TACT SWITCH
S 931 QSW0674-001Z TACT SWITCH DUBBING
S 932 QSW0674-001Z TACT SWITCH
S 933 QSW0674-001Z TACT SWITCH
S 935 QSW0674-001Z TACT SWITCH
S 936 QSW0674-001Z TACT SWITCH
S 937 QSW0674-001Z TACT SWITCH
S 938 QSW0674-001Z TACT SWITCH
S 939 QSW0674-001Z TACT SWITCH
S 942 QSW0674-001Z TACT SWITCH
S 943 QSW0674-001Z TACT SWITCH
S 944 QSW0674-001Z TACT SWITCH
S 945 QSW0674-001Z TACT SWITCH
S 946 QSW0674-001Z TACT SWITCH
S 947 QSW0674-001Z TACT SWITCH
S 948 QSW0674-001Z TACT SWITCH
S 949 QSW0674-001Z TACT SWITCH
S 950 QSW0674-001Z TACT SWITCH
S 951 QSW0674-001Z TACT SWITCH
S 952 QSW0674-001Z TACT SWITCH
S 963 QSW0674-001Z TACT SWITCH
S 964 QSW0674-001Z TACT SWITCH
S 995 QSW0674-001Z TACT SWITCH
S 996 QSW0674-001Z TACT SWITCH
S 997 QSW0674-001Z TACT SWITCH
S 998 QSW0674-001Z TACT SWITCH
S 999 QSW0674-001Z TACT SWITCH
SP801 VYH7653-001 IC HOLDER
X 801 QAX0283-001Z RESONATOR
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Area
Remarks
A
