MX-GT91R
3-22
Item
Parts number Parts name Area
Remarks
A
C 251 NCS21HJ-100X C CAPACITOR
C 252 NCS21HJ-100X C CAPACITOR
C 253 NCB21EK-104X C CAPACITOR
C 254 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 291 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 601 NCB21HK-102X C CAPACITOR
C 602 NCB21HK-102X C CAPACITOR
C 603 NCB21HK-223X C CAPACITOR
C 604 NCB21HK-223X C CAPACITOR
C 605 NCS21HJ-151X C CAPACITOR
C 606 NCS21HJ-560X C CAPACITOR
C 608 NCS21HJ-821X C CAPACITOR
C 610 NCB21EK-273X C CAPACITOR
C 612 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 613 NCB21EK-104X C CAPACITOR
C 614 NCB21HK-273X C CAPACITOR
C 615 NCB21HK-472X C CAPACITOR
C 616 NCB21HK-103X C CAPACITOR
C 617 NCS21HJ-331X C CAPACITOR
C 620 NCS21HJ-470X C CAPACITOR
C 621 NCB21CK-105X C CAPACITOR
C 622 NCB21EK-473X C CAPACITOR
C 623 NCF21CZ-105X C CAPACITOR
C 624 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 631 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 632 NCF21CZ-105X C CAPACITOR
C 633 NCB21HK-223X C CAPACITOR
C 641 NCB21HK-223X C CAPACITOR
C 642 NCB21HK-222X C CAPACITOR
C 651 NCS21HJ-120X C CAPACITOR
C 652 NCS21HJ-120X C CAPACITOR
C 653 NCB21EK-104X C CAPACITOR
C 655 NCB21EK-104X C CAPACITOR
C 656 NCB21EK-104X C CAPACITOR
C 657 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 658 NCB21EK-104X C CAPACITOR
C 661 NCS21HJ-471X C CAPACITOR
C 663 NCB21HK-223X C CAPACITOR
C 664 NCB21HK-223X C CAPACITOR
C 665 NCB21CK-154X C.CAPACITOR
C 667 NCB21CK-105X C CAPACITOR
C 668 NCB21EK-473X C CAPACITOR
C 669 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 672 NCB21CK-334X C CAPACITOR
C 673 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 676 NCB21EK-104X C CAPACITOR
C 677 NCB21EK-104X C CAPACITOR
C 679 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 680 NCB21EK-104X C CAPACITOR
C 691 NCS21HJ-391X C CAPACITOR
C 692 NCS21HJ-391X C CAPACITOR
C 693 NCB21HK-682X C.CAPA. C.M
C 694 NCB21HK-682X C.CAPA. C.M
C 695 NCB21HK-473X C CAPACITOR
C 696 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 699 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 801 NCB21HK-682X C.CAPA. C.M
C 802 NCB21HK-123X C CAPACITOR
C 811 NCS21HJ-391X C CAPACITOR
C 812 NCS21HJ-391X C CAPACITOR
C 813 NCS21HJ-391X C CAPACITOR
C 814 NCS21HJ-391X C CAPACITOR
C 815 QEQF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 821 NCF21CZ-105X C CAPACITOR
C 822 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 852 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 853 NCB21HK-103X C CAPACITOR
C 854 NCB21HK-103X C CAPACITOR
C 855 NCB21EK-104X C CAPACITOR
C 859 NCF21CZ-105X C CAPACITOR
C 860 NCF21CZ-105X C CAPACITOR
CN601 QGF1016F3-15 15FFC CONNECTOR
CN651 QGF1016F3-19 CONNECTOR
CN801 QGA2001C1-06 6P PLUG ASSY
CN854 QGB2016K1-07 CONNECTOR
CN855 QGB2012K2-10 CONNECTOR
D 851 MTZJ5.6B-T2 ZENER DIODE
IC251 UPD780024AGKB25 ONETIME PP ONLY
IC601 AN22000A IC
IC651 MN662748RPM IC
IC652 BA15218F-XE IC
IC801 LA6541-X IC
IC851 LB1641 IC
IC852 LB1641 IC
L 851 QQL01BK-100Z INDUCTOR
L 853 QQL01BK-100Z INDUCTOR
L 854 QQL01BK-100Z INDUCTOR
Q
291 2SB1357/EF/-T TRANSISTOR
Q
631 2SA1037AK/RS/-X TRANSISTOR
R 253 NRSA02J-102X MG RESISTOR
R 254 NRSA02J-102X MG RESISTOR
R 255 NRSA02J-102X MG RESISTOR
R 256 NRSA02J-102X MG RESISTOR
R 257 NRSA02J-102X MG RESISTOR
R 258 NRSA02J-102X MG RESISTOR
R 260 NRSA02J-222X MG RESISTOR
R 261 NRSA02J-223X MG RESISTOR
R 262 NRSA02J-223X MG RESISTOR
R 263 NRSA02J-223X MG RESISTOR
R 264 NRSA02J-223X MG RESISTOR
R 265 NRSA02J-223X MG RESISTOR
R 274 NRSA02J-102X MG RESISTOR
R 275 NRSA02J-102X MG RESISTOR
R 276 NRSA02J-102X MG RESISTOR
R 277 NRSA02J-102X MG RESISTOR
R 280 NRSA02J-102X MG RESISTOR
R 281 NRSA02J-102X MG RESISTOR
R 284 NRSA02J-102X MG RESISTOR
R 288 NRSA02J-102X MG RESISTOR
R 289 NRSA02J-102X MG RESISTOR
R 290 NRSA02J-102X MG RESISTOR
R 291 NRSA02J-122X MG RESISTOR
R 292 NRSA02J-103X MG RESISTOR
R 294 NRSA02J-102X MG RESISTOR
R 601 NRSA02J-224X MG RESISTOR
R 602 NRSA02J-274X MG RESISTOR
R 603 NRSA02J-124X MG RESISTOR
R 604 NRSA02J-274X MG RESISTOR
R 606 NRSA02J-623X MG RESISTOR
R 607 NRSA02J-0R0X MG RESISTOR
R 608 NRSA02J-0R0X MG RESISTOR
R 609 NRSA02J-332X MG RESISTOR
R 611 NRSA02J-223X MG RESISTOR
R 613 NRSA02J-222X MG RESISTOR
R 614 NRSA02J-223X MG RESISTOR
R 618 NRSA02J-153X MG RESISTOR
Electrical parts list (CD servo control board)
Block No. 05
Item
Parts number Parts name Area
Remarks
A
