JVC MX-GT91R User Manual

MX-GT91R
3-23
Item
Parts number Parts name Area
Remarks
A
R 619 NRSA02J-153X MG RESISTOR
R 620 NRSA02J-564X MG RESISTOR
R 621 NRSA02J-564X MG RESISTOR
R 622 NRSA02J-822X MG RESISTOR
R 623 NRSA02J-822X MG RESISTOR
R 624 NRSA02J-0R0X MG RESISTOR
R 625 NRSA02J-0R0X MG RESISTOR
R 631 NRSA02J-2R2X MG RESISTOR
R 632 NRSA02J-100X MG RESISTOR
R 634 NRSA02J-120X MG RESISTOR
R 635 NRSA02J-121X MG RESISTOR
R 636 NRSA02J-100X MG RESISTOR
R 641 NRSA02J-154X MG RESISTOR
R 642 NRSA02J-394X MG RESISTOR
R 651 NRSA02J-102X MG RESISTOR
R 652 NRSA02J-102X MG RESISTOR
R 653 NRSA02J-102X MG RESISTOR
R 654 NRSA02J-101X MG RESISTOR
R 655 NRSA02J-102X MG RESISTOR
R 656 NRSA02J-102X MG RESISTOR
R 657 NRSA02J-102X MG RESISTOR
R 658 NRSA02J-102X MG RESISTOR
R 659 NRSA02J-102X MG RESISTOR
R 661 NRSA02J-393X MG RESISTOR
R 662 NRSA02J-683X MG RESISTOR
R 663 NRSA02J-124X MG RESISTOR
R 664 NRSA02J-331X MG RESISTOR
R 665 NRSA02J-271X MG RESISTOR
R 666 NRSA02J-221X MG RESISTOR
R 667 NRSA02J-4R7X MG RESISTOR
R 668 NRSA02J-155X MG RESISTOR
R 669 NRSA02J-562X MG RESISTOR
R 670 NRSA02J-101X MG RESISTOR
R 672 NRSA02J-272X MG RESISTOR
R 682 NRSA02J-102X MG RESISTOR
R 683 NRSA02J-105X MG RESISTOR
R 684 NRSA02J-564X MG RESISTOR
R 685 NRSA02J-683X MG RESISTOR
R 689 NRSA02J-103X MG RESISTOR
R 690 NRSA02J-103X MG RESISTOR
R 691 NRSA02J-103X MG RESISTOR
R 692 NRSA02J-103X MG RESISTOR
R 695 NRSA02J-243X MG RESISTOR
R 696 NRSA02J-243X MG RESISTOR
R 701 NRSA02J-821X MG RESISTOR
R 702 NRSA02J-821X MG RESISTOR
R 703 NRSA02J-103X MG RESISTOR
R 704 NRSA02J-103X MG RESISTOR
R 705 NRSA02J-562X MG RESISTOR
R 706 NRSA02J-202X MG RESISTOR
R 707 NRSA02J-682X MG RESISTOR
R 708 NRSA02J-101X MG RESISTOR
R 709 NRSA02J-101X MG RESISTOR
R 710 NRSA02J-221X MG RESISTOR
R 801 NRSA02J-272X MG RESISTOR
R 802 NRSA02J-392X MG RESISTOR
R 803 NRSA02J-222X MG RESISTOR
R 804 NRSA02J-224X MG RESISTOR
R 805 NRSA02J-133X MG RESISTOR
R 806 NRSA02J-243X MG RESISTOR
R 807 NRSA02J-122X MG RESISTOR
R 808 NRSA02J-273X MG RESISTOR
R 809 NRSA02J-122X MG RESISTOR
R 811 NRSA02J-103X MG RESISTOR
R 812 NRSA02J-152X MG RESISTOR
R 831 NRSA02J-151X MG RESISTOR
R 832 NRSA02J-103X MG RESISTOR
R 842 NRSA02J-472X MG RESISTOR
R 851 NRSA02J-102X MG RESISTOR
R 852 NRSA02J-102X MG RESISTOR
R 853 NRSA02J-102X MG RESISTOR
R 854 NRSA02J-102X MG RESISTOR
R 856 NRSA02J-0R0X MG RESISTOR
R 861 NRSA02J-102X MG RESISTOR
R 862 NRSA02J-102X MG RESISTOR
R 863 NRSA02J-102X MG RESISTOR
R 864 NRSA02J-102X MG RESISTOR
R 865 NRSA02J-102X MG RESISTOR
R 866 NRSA02J-102X MG RESISTOR
R 871 NRSA02J-223X MG RESISTOR
R 872 NRSA02J-223X MG RESISTOR
R 873 NRSA02J-223X MG RESISTOR
R 874 NRSA02J-223X MG RESISTOR
R 875 NRSA02J-223X MG RESISTOR
R 876 NRSA02J-223X MG RESISTOR
R 880 NRSA02J-102X MG RESISTOR
R 881 NRSA02J-102X MG RESISTOR
R 882 NRSA02J-102X MG RESISTOR
R 883 NRSA02J-102X MG RESISTOR
R 884 NRSA02J-102X MG RESISTOR
R 885 NRSA02J-102X MG RESISTOR
R 886 NRSA02J-102X MG RESISTOR
R 887 NRSA02J-102X MG RESISTOR
R 888 NRSA02J-223X MG RESISTOR
R 889 NRSA02J-223X MG RESISTOR
R 890 NRSA02J-223X MG RESISTOR
R 891 NRSA02J-223X MG RESISTOR
R 892 NRSA02J-223X MG RESISTOR
R 893 NRSA02J-223X MG RESISTOR
R 894 NRSA02J-223X MG RESISTOR
R 895 NRSA02J-223X MG RESISTOR
X 251 QAX0360-001Z CRYSTAL
X 651 QAX0413-001Z CRYSTAL
Item
Parts number Parts name Area
Electrical parts list (CD select switch board)
Remarks
Block No. 06
A
CN804 QGB2016J1-07 CONNECTOR
CN805 QGB2012J1-10 CONNECTOR
SW 1 QSW0859-001 DETECT SWITCH
SW 2 QSW0859-001 DETECT SWITCH
SW 3 QSW0859-001 DETECT SWITCH
SW 4 QSW0859-001 DETECT SWITCH
SW 5 QSW0859-001 DETECT SWITCH
SW 6 QSW0859-001 DETECT SWITCH
Electrical parts list (CD servo control board)
Block No. 05
Item
Parts number Parts name Area
Remarks
A
