English
Center unit section – CA-MXJ333V/CA-MXJ383V
Amplifier
Output Power
53 watts per channel, min. RMS, both channels driven into 6
ohms at 1 kHz with no more than 0.9% total harmonic distortion.
Audio input sensitivity/Impedance (at 1 kHz)
AUX: 300 mV/50 kohms
MIC 1/2: 3 mV/5 kohms
Speakers/Impedance: 6 – 16 ohms
Tuner
FM tuning range: 87.50 – 108.00 MHz
AM tuning range:
For Saudi Arabia:
At 9 kHz intervals : 531 – 1,602 kHz
At 10 kHz intervals : 530 – 1,600 kHz
For other countries:
At 9 kHz intervals : 531 – 1,710 kHz
At 10 kHz intervals : 530 – 1,710 kHz
CD player
CD Capacity: 3 CDs
Dynamic range: 85 dB
Signal-to-noise ratio: 90 dB
Wow and flutter: Immeasurable
Cassette deck
Frequency response
Normal (type I): 50 – 14,000 Hz
CrO2 (type II): 50 – 14,000 Hz
Metal (type IV): 50 – 14,000 Hz (only for playback)
Wow and flutter: 0.15% (WRMS)
General
Power requirement: AC 110/127/220/230-240 V
(adjustable with the voltage selector),
50 / 60 Hz
Power consumption: 90 watts (at operation)
16watts (at standby mode)
Maximum power consumption (for Taiwan only): 300 watts
Dimensions (approx.): 265 x 315 x 341 mm (W/H/D)
(10
7
/16 x 12
7
/16 x 13
7
/16 in.)
Mass (approx.): 8.4 kg (18.5 lbs)
Colour
MX-J333V Silver colour model
MX-J383V Gold colour model
Supplied accessories
See page 3.
Speaker section – SP-MXJ333/SP-MXJ383
Type: 3-way bass-reflex type
Speaker units: Woofer: 15cm (5
15
/16") cone x1
Midrange: 5cm (2") cone x1
Tweeter: 2cm (
13
/16") dome x1
Power handling capacity: 100 watts
Impedance: 6 ohms
Frequency range: 45 Hz – 22,000 Hz
Sound pressure level: 88 dB/W•m
Dimension (approx): 215 X 315 X 230 mm (W/H/D)
(8
1
/2 X 12
7
/16 X 9
1
/16 in)
Mass (approx): 3.3 kg (7.3 lbs) each
Design and specifications are subject to change without notice.
