MX-J570V/MX-J680V
3-17
Item
Parts number Parts name Area
Electrical parts list (Main & pri-AMP. board)
Remarks
Block No. 02
A
C 350 FQDYB1CM-103Y C CAPACITOR
C 351 EETC1HM-226ZJC E CAPACITOR
C 352 EETC1HM-226ZJC E CAPACITOR
C 360 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 361 FQDYB1CM-103Y C CAPACITOR
C 362 EETC1HM-226ZJC E CAPACITOR
C 366 EETC1HM-226ZJC E CAPACITOR
C 367 FQDYB1CM-103Y C CAPACITOR
C 370 FQDYB1CM-103Y C CAPACITOR
C 371 EETC1HM-226ZJC E CAPACITOR
C 372 EETC1HM-226ZJC E CAPACITOR
C 373 FQDYB1CM-103Y C CAPACITOR
C 374 EETC1HM-226ZJC E CAPACITOR
C 801 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V
C 803 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 804 QETN0JM-108Z E CAPACITOR 1000MF 20% 6.3V
C 805 FQDGB1HK-102Y C CAPACITOR
C 806 FQDGB1HK-102Y C CAPACITOR
C 807 QCS11HJ-390 C CAPACITOR 39PF 5% 50V
C 808 FQCSB1HJ-330Y C CAPACITOR
C 809 FQCSB1HJ-330Y C CAPACITOR
C 810 QCS11HJ-390 C CAPACITOR 39PF 5% 50V
C 811 FQDGB1HK-102Y C CAPACITOR
C 812 FQCSB1HJ-220Y C CAPACITOR
C 813 FQCSB1HJ-270Y C CAPACITOR
C 814 QETN0JM-108Z E CAPACITOR 1000MF 20% 6.3V
C 815 EETC1HM-226ZJC E CAPACITOR
C 816 EETC1CM-476ZJC E CAPACITOR
C 817 EETC1HM-226ZJC E CAPACITOR
C 820 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 821 FQDYB1CM-103Y C CAPACITOR
C 823 QFVJ1HJ-334Z M CAPACITOR .33MF 5% 50V
C 831 FQDYB1CM-103Y C CAPACITOR
C 832 FQDYB1CM-103Y C CAPACITOR
C 834 EEKC1HM-226ZJC E CAPACITOR
C 835 FQDGB1HK-102Y C CAPACITOR
C 855 EETC0JM-227ZJC E CAPACITOR
C 856 EETC1AM-107ZJC E CAPACITOR
C 857 EEKC1CM-476ZJC E CAPACITOR
C 862 EEKC1HM-475ZJC E CAPACITOR
C 870 FQDYB1CM-103Y C CAPACITOR
C 871 EETC1HM-475ZJC E CAPACITOR
C 872 EEKC1HM-224ZJC E CAPACITOR
C 876 EETC1HM-105ZJC E CAPACITOR
C 877 FQDGB1HK-681Y C CAPACITOR
C 878 FQDXB1CM-182Y C CAPACITOR
C 879 FQCSB1HJ-330Y C CAPACITOR
C 880 QFLM1HJ-153Z M CAPACITOR .015MF 5% 50V
C 881 EEKC1HM-225ZJC E CAPACITOR
C 882 EEKC1HM-225ZJC E CAPACITOR
C 883 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C 884 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C 885 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V
C 886 QFLM1HJ-103Z M CAPACITOR .010MF 5% 50V
C 887 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 889 EEKC1HM-105ZJC E CAPACITOR
C 890 FQDGB1HK-102Y C CAPACITOR
C 950 FQDYB1CM-103Y C CAPACITOR
C 951 FQDYB1CM-103Y C CAPACITOR
C 991 FQDYB1CM-103Y C CAPACITOR
C 992 FQDYB1CM-103Y C CAPACITOR
CN602 QGB2510K2-04 CONNECTOR
CN713 VMC0107-R06 4P PLUG ASSY
CN815 QGD2504C1-03Z SOCKET
CN850 QGD2504C1-03Z SOCKET
CN851 QGD2504C1-04Z SOCKET
CN860 QGB1214K1-20S CONNECTOR
CN861 QGB1214K1-20S CONNECTOR
CN862 QGD2504C1-03Z SOCKET
CN863 QGD2504C1-03Z SOCKET
CN865 QGF1205C1-09 CONNECTOR
CN867 QGA2501C1-02 2P CONNECTOR
CN868 QGF1016C1-19 CONNECTOR
CN869 QGF1205C1-11 CONNECTOR
CN879 QGF1031C1-09S FFC/FPC CONNE
CN880 QGF1205C1-11 CONNECTOR
CN883 QGD2504C1-03Z SOCKET
CN884 QGD2504C1-03Z SOCKET
CN900 QGD2504C1-04Z SOCKET
CN901 QGD2504C1-04Z SOCKET
CN905 QGF1205C1-11 CONNECTOR
CN906 QGF1205C1-11 CONNECTOR
CN979 QGF1016F1-09 CONNECTOR
CN990 QGF1205F1-11 CONNECTOR
C1003 FQDGB1HK-102Y C CAPACITOR
C1004 FQDGB1HK-102Y C CAPACITOR
C1005 FQDGB1HK-102Y C CAPACITOR
C1006 FQDGB1HK-102Y C CAPACITOR
D 350 MTZJ11C-T2 ZENER DIODE
D 351 MTZJ12C-T2 ZENER DIODE
D 360 MTZJ5.1B-T2 ZENER DIODE
D 361 MTZJ11C-T2 ZENER DIODE
D 362 MTZJ6.8C-T2 ZENER DIODE
D 365 MTZJ9.1B-T2 ZENER DIODE
D 366 MTZJ11C-T2 ZENER DIODE
D 367 MTZJ10C-T2 ZENER DIODE
D 368 MTZJ11C-T2 ZENER DIODE
D 369 MTZJ10C-T2 ZENER DIODE
D 370 MTZJ11C-T2 ZENER DIODE
D 801 1N4003S-T5 SI DIODE
D 803 1SS119-02-T2 SI DIODE
D 804 1SS133-T2 SI DIODE
D 805 1SS133-T2 SI DIODE
D 831 MTZJ5.1B-T2 ZENER DIODE
D 832 MTZJ5.1B-T2 ZENER DIODE
D 853 MTZJ8.2C-T2 ZENER DIODE
D 860 1SS133-T2 SI DIODE
D 871 1SS133-T2 SI DIODE
D 872 1SS133-T2 SI DIODE
D 873 1SS133-T2 SI DIODE
D 955 SLR-342MC-T LED
D 956 SLR-342MC-T LED
D 957 SLR-342MC-T LED
D 958 SLR-342MC-T LED
D 961 1SS133-T2 SI DIODE
D 962 SLA-370LT3F LED POWER LED
D 981 SLR-342MC-T LED
D 982 SLR-342MC-T LED
D 983 SLR-342MC-T LED
D 984 SLR-342MC-T LED
EP201 E409182-001SM GRAND TERMINAL
FL801 QLF0074-001 FL TUBE
FW714 QUM155-11DGZ4 FLAT WIRE
FW850 QUM153-06Z4Z4 FLAT WIRE
FW862 QUM026-26DGZ4 FLAT WIRE
FW883 QUM026-26DGZ4 FLAT WIRE
Item
Parts number Parts name Area
Remarks
A
